UNPACKING INSTRUCTION

CAUTION! Immediately upon receiving the product, carefully unpack the carton, check the contents to ensure that all parts are
present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if
any parts appear damage from shipping or the package itself shows signs of mishandling. Save the package and all packing
materials. In the event that the product must be returned to the factory, it is important that the product be returned in the original
factory box and packing.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately. The
arising condensation water might damage your device. Leave the device switched off until it has reached room temperature.

CONTROL PANEL

1. SCRATCH BUTTON
When scratch mode is active, turn jog/shuttle wheel clockwise or counter clockwise for scratch effects
2. USB PORT
You can play sound files from a USB device by connecting the device to this slot
3. SOURCE BUTTON
Toggle the audio source: USB port, Aux in and Bluetooth
4. MIC VOLUME KNOB
Controls microphone input volume
5. MIC JACK INPUT
Connect a wired microphone
6. AUX JACK INPUT
You can connect your music device to this socket with a 3.5mm jack cable
7. BLUETOOTH BUTTON
See chapter "CONNECTING WITH BLUETOOTH" for detailed instructions on how to set up a BT connection
8. PITCH CONTROL
Rotating the knob will increase the pitch when moved towards [+] and decrease the pitch when moved towards [-]
9. JOG & SHUTTLE WHEELS
Shuttle: Use the dial to select the scanning direction and speed. The disc is scanned in the forward direction when the
shuttle dial is turned clockwise from the neutral position, in the reverse direction when the shuttle dial is turned
counterclockwise. The scanning speeds up when the shuttle dial is turned faster.
Jog: In pause mode, if you turn the jog, the point at which the sound is being produced moves by a number of frames
corresponding to the number of clicks. Clockwise moves the point forward; counterclockwise moves the point backward. In
play mode, the jog increases or decreases the speed of the song (Clockwise: increase, counterclockwise: decrease).
10. LCD DISPLAYS
LCD Display indicates multiple types of information: Track/Time/Remain/Pitch/Continue/Single, Repeat/etc.
