TP active fun TP321 Montageanleitung Seite 16

TP321 Chalet IN3211 Issue B 03 15.qxp_TP321 Chalet IN3211 Issue B 03 15 26/03/2015 10:45 Page 16
Stage
14
x17
MW2014 (966mm)
x34
4.5 x 30mm Woodscrew
SSEMBLY TIP
1
Fix roof panel
boards at the top
first.
5
6
7
8
9
10
11
TP Chalet
16
