INTRODUCTION
Congratulations on your purchase. Please read all instructions carefully before you
use your device.
You can use the QUINTEZZ HD DASHCAM inside your car for recording your rides and
dangerous situations or accidents on the road during driving.
PACKAGE CONTENTS
See illustration I
1.
Camera DVR unit
a. POWER : Turn device on/off (Press & hold for turning on/off when not connected
to power source)
b. MENU : Enter/exit the menu
c. MODE/OK : Confirm the selected option
d. UP : Go up or 1/2/3/4 x digital zoom in
e. DOWN : Go down or 1/2/3/4 x digital zoom out
f. MODE : Mode switching between VIDEO recording / PHOTO / AUDIO recording/
PLAYBACK / Confirm the selected option
2.
Mounting bracket
3.
12/24V DC 5V – 1000 mA Car charger
4.
USB connection cable
5.
TV OUT cable
6.
Battery BL-5C
CHARGING
The device has a built-in Li-ion rechargeable battery that has to be fully charged
and decharged 3 times to activate the maximum capacity of the battery. Charging
time is about 4 hours maximum.
When the battery is completely charged, the display will show a "full battery"
symbol. Operation time without connection to a power source is max. 1 hour.
Placing the battery:
See illustration II
Open the battery compartment at the top of the unit. Place the battery. Make sure the
battery is placed in the correct position. Close the battery compartment by placing the
cover back in its place.
Charging options:
Connect the device to a computer/laptop using the USB connection cable (4).
OR
Plug the device into the included car charger (3) for car/truck use.
USE OF THE QUINTEZZ HD DASHCAM
MODES
Attention! This menu will not function when PC camera mode is active.
VIDEO RECORDING MODE
A red camera icon would be shown in the upper left corner of the display.
When the QUINTEZZ HD DASHCAM is connected to your cars power
supply, it will start Video recording as soon as the car engine is started. It
will stop recording after the car is stopped.
When the QUINTEZZ HD DASHCAM is not connected to the cars power
supply, press the POWER button (a), and press the OK button (c) to start
recording. The unit will automatically be in Video recording mode. Press
OK (c) again to stop recording and save the files automatically.
Loop recording: During recording, the device will save each video file every
2, 5 or 10 minutes automatically. When the SD card is full, the device will
delete the oldest video file automatically.
Note:
The Infrared video recording function is turned on automatically under low-
light circumstances.
PHOTO MODE
A photo icon would be shown in the upper left corner of the display.
Press the MODE button (f) 1x if you want to make pictures instead of
recordings.
Press the OK button (c) every time you want to take a picture.
AUDIO RECORDING MODE
An audio icon would be shown in the upper left corner of the display.
Press the MODE button (f) 2x if you want to make Audio recordings only,
and press OK (c) to start recording.
Press OK (c) again to stop recording and save the files automatically.
Press the "UP" button (d) to pause or begin recording again.
PLAYBACK MODE
A playback icon would be shown in the upper left corner of the display.
For Playback mode, press the MODE button (f) 3x.
MENU SETTINGS
Attention! This menu will not function
when PC camera mode is active.
1.
Power on the unit using the supplied
car charger or the charged battery.
2.
Press MODE (f) until you have
selected the desired mode.
3.
Press MENU (b) to enter the menu.
4.
Press UP/DOWN buttons (d-e)
to scroll through the submenu's.
5.
After selection, click OK (c) or MODE
(f) to confirm and save the setting.
6.
Press MENU (b) to exit.
For example: to set date and time, please
follow these steps:
1.
Make sure the battery is charged.
2.
Turn the Dashcam ON (or use it with
the car charger in the car).
3.
Press MENU (b).
4.
Press MODE (f).
5.
Use the DOWN (e) button to go to
DATE & TIME.
6.
Press the OK/RECORD button (c) at
the top of the Dashcam (next to the
ON/OFF button).
7.
You can now use the UP & DOWN
buttons (d-e) to change the date and
time and confirm each setting by
pressing the MODE button (f).
8.
As soon as you are ready, you should
press MENU (b) or OK (c) to confirm the
settings.
SYSTEM SETTINGS
Attention! This menu will not function when PC camera mode is
active.
1.
Power on the unit.
2.
Press MENU (b) to enter the menu when the device is in recording
mode.
3.
Press MODE (f) until you can select the Setup menu. Press OK
(c) to select.
4.
Use the UP/DOWN buttons (d-e) to scroll through the
submenu's.
5.
After selection, click MODE (f) or OK (c) to confirm and save the
setting.
6.
Press MENU (b) to exit.
7.
Settings will be changed after restart of the unit.
CUSTOMER SUPPORT
For all product related questions, please contact:
support@quintezz.com
GUARANTEE
Copyright©Quintezz. Quintezz is a registered trademark of TE-
Group NV. The Quintezz brand stands for superior product
quality and outstanding customer service. That is why
Quintezz warrants this product against all defects in material
and workmanship for a period of two (2) years from the date
of original purchase of the product. The conditions of this
guarantee and the extent of responsibility of Quintezz under
this guarantee can be downloaded from our website:
www.quintezz.com.
VIDEO MENU
Movie Size
(HD) 1280x720
Video resolution
(D1) 848x480
(640) 640x480
Date stamp
Off
Date indication
Date&Time
during recording
Motion Detect *
Off *
Automatic recording
On
when movement is
detected when used
on battery.
Loop Rec. *
Off
Cycle recording
On *
Loop Time *
2 min *
Saving time of each
5 min
section on SD card
10 min
Continue *
Off *
Power off delay,
10 min
when using without
20 min
power source
Video sound
On
Sound recording
Off
Sounds
Power frequency
Power save
Automatic power
off when use on
battery
Panel protect
Screensaver when
used on battery.
Date & Time
GB
As soon as the car engine is started, the recording will start. The QUINTEZZ HD DASHCAM
will now be charged during recording. When the car charger is disconnected from the unit,
the QUINTEZZ DASHCAM will shut down automatically and save the files.
Caution: With low battery, the QUINTEZZ HD DASHCAM will enter into protection state.
Please charge the battery to make sure you can turn on the device.
USING SD CARD (not supplied, optionnally available)
See illustration III
Open the SD card slot at the side of the unit.
Insert your SD card into the SD slot until it clicks into place.
To remove the SD Card, press the card lightly. It is partially ejected allowing you to
pull the card out.
With no card in the SD slot, the displays shows "No card".
Note:
1.
We recommend using a 4GB SDHC card (or higher) with class 6 (or higher).
(not supplied, optionnally available)
2.
Without SD card, the unit will NOT function!
3.
If the SD card is inserted in a wrong way (difficult to insert), it may damage the
device and the memory card.
4.
The device will set the SD card after it has been inserted.
VIDEO*
SD CARD
1280X720
848X480
32GB
480 min
480 min
16 GB
240 min
240 min
8GB
120 min
120 min
4GB
60 min
60 min
* Depends on SD card brand, model and class type. Data are approximate.
MOUNTING
See illustration IV
Mount the DVR unit (1) to the mounting bracket (2).
Moisten the suction cup, place it on the inside of your windshield and close the
cup using the lever. We recommend placing the QUINTEZZ HD DASHCAM on the
right side of the rear view mirror.
Adjust the bracket by using the adjustment knobs.
Make sure the camera is mounted horizontal for the best view.
Connect the car charger (3) to the car lighter for power.
Using the UP and DOWN buttons (d-e) you can scroll through the recordings.
Press OK (c) to start playback.
Press the "UP" button (d) to pause or begin playback again.
PC CAMERA MODE
You can connect the QUINTEZZ HD DASHCAM to your PC by using the
supplied USB cable (4). You can use it to backup or playback files on your PC.
Press the UP/DOWN buttons (d-e) to choose the mode:
»
MSDC : It is a computer interface between a computer and a digital
camera which shows the digital camera as a removable disk drive
attached to the computer.
»
PC Cam: A webcam is a video camera which feeds its images in real
time to a computer or computer network via USB.
»
Recording mode: Press the OK button to start video recording.
You don't need to install drivers to use the HD Dashcam with your PC because
these are already installed by Windows in the Windows pack*.
You should connect the HD Dashcam as following :
1.
Make sure the battery is charged.
2.
Only use the SUPPLIED USB cable.
3.
Turn the Dashcam ON.
4.
Connect the USB cable with the Dashcam (behind the lid at the left side) and
only then with the PC.
5.
Select "MSDC" or "PCCAM"on the Dashcam and press the OK/RECORD button
(c) (next to the ON/OFF button).
6.
The driver will now install itself and in the folder "My computer" on your
desktop you will see a new (hard)disk (it is possible that a window will appear
in which you can indicate how you would like to view the files). The PCCAM
driver will be installed separately when PCCAM is selected.
7.
You can now see all files in the folder and double-click them to watch the videos using
the standard Windows Media Player or Apple Quicktime (you can select yourself).
Note:
• You can also remove the SD card from the Dashcam and place it in a (built-in)
SD card reader from your PC or a separate SD card reader if you have one. This
is a quick and easy-to-use solution.
* In case of a conflict, when the camera is not recognized or not installed correctly,
you can download the USB drivers from the website www.quintezz.com.
PHOTO MENU
Resolution
(5MP) 2592x1944
(3MP) 2048x1536
(2MP) 1600x1200
(1MP) 1280x1024
Quality
Super Fine
Fine
Normal
Exposure
-2.0/ -1.7/ -1.3/
Luminance
-1.0/ -0.7/ -0.3/
adjustment
+0.0/ +0.3/ +0.7/
+1.0/ +1.3/ +1.7/
+2.0
Capture Mode
Off
Photo timer
Self-timer 2S
Self-timer 10S
Burst
Date stamp
Off
Date indication
Date&Time
on photo
* Recommended setting.
Shutter
Shutter sound
Start-up
Select start-up
sound
Beep
Key tone
Volume
50 Hz
60 Hz
1 Min
3 Min
5 Min
Off
30sec.
1min.
2min.
OFF
Year
Month
Day
Hour
Minute
Time Style
640X480
1280X1024
1600X1200 2048X1536
520 min
24320
23040
260 min
12160
11520
140 min
6080
5760
80 min
3040
2880
PLAYBACK MENU
Lock
File locking
Delete
File removal
Slide show
Voice memo
Start-up image
Select image as
start-up image
On
Language
English, Dutch, French, Spanish
Off
Italian, Portuguese, Czech,
Hungarian, Swedish, Russian
None
Polish, German, Turkish, Greek
1
2
TV OUT
3
TV system
On
TV OUT: Connect the TV OUT cable (5) to
a TV for watching the recorded videos
Off
and photos.
0/ 1/ 2/ 3
Start-up image
Format
Formatting the
SD card
If you would have problems with
your SD card (like "memory full") we
advise you to format the card using
this menu, and make a "reset all*" to
factory settings
IR LED
Night vision
*Reset all
Reset to factory
settings
Version
MM/DD/YYYY
Software version information
DD/MM/YYYY
YYYY/MM/DD
IMAGE*
2592X1944
21920
18880
10960
9440
5530
4720
2760
2360
Lock/Unlock one
Lock All
Unlock All
One
All
Start
Interval
Repeat
Add
Delete
Set
Cancel
NTSC
PAL
Off
System
My image
Yes
No
Off
On
Yes
No

Werbung

loading
