IRT 3 PrepCure
1. Assembly Instructions
1.1
16 mm (2x)
Power feeding cable
Strain relief for cable
Screw MVBF M10x60 (2x)
Screw M6x20 PH
Screw M6S M10x25 fz (4x)
Washer BRB 10,5x20x2 (6x)
Nut M10 Locknut (6x)
1.2
Phillips 2
Screw MVBF M12x60 Fz
Washer BRB M13 Fz
1.3
Screw MRX M6x40 Ph (x2)
Washer Star Locking M6 (x2)
Spacer (x2)
Phillips 2
10 mm
3
714377 rev 2
