GB
Encoding (Fig. 3)
Also observe the wireless receiver's operating instructions for encoding.
1) Place the wireless motion sensor near to the wireless receiver.
2) When the wireless receiver is ready to learn, the wireless motion
sensor's learn button (L) must be briefly pressed 1x for the ON signal.
The wireless receiver now activates 2x, indicating that the new
transmitter has been saved.
Proceed as described above to erase codes, though now the learn but-
ton (L) must be briefly pressed 2x consecutively for the OFF signal.
Mounting (Fig. 4)
The wireless motion detector can easily be set up on any flat surface
such as a table or shelf. Make sure that the lens' square fields are pointing
downwards.
The motion detector can be mounted on walls, ceilings, etc. using the
mounting magnet included.
Screw the mounting magnet into the desired position.
The motion detector is held in place with magnetic force and can be
placed in various positions and inclinations enabling you to define a
precisely defined detection range.
Range and angle of the detection range (Fig. 5)
Battery replacement (Fig. 6)
If the battery is running out a red LED will shine every 4 seconds.
Remove the back of the motion sensor.
Use a screwdriver to lift the battery out of the metal clip. Insert the new
3V CR 2450 battery into the metal clip starting with the + sign facing
upwards.
Replace the back.
A new battery has an operating life of around 20,000 operations or 3
years.
Safety instruction:
BATTERIES
Do not ingest batteries, risk of burning due to dangerous substances.
This product contains a button cell battery. If the button cell battery
is swallowed, severe internal burns can occur within just 2 hours and
cause death. Keep new and used batteries out of the reach of children.
Operating instructions
PIR-3000
›
