LevelOne HDBaseT Series Schnellinstallationsanleitung Seite 5

Panel Description Receivers
HVE-9211R / HVE-9211PR Front
5 6
HVE-9211R Back
10
HVE-9211PR Back
1) Power Indicator 2) Tx Link Active
4) HDCP Link Port2 5) IR Cable Out
7) RS-232
10) Power In (optional for HVE-9212PR)
9 8
9
8
8) HDMI Out
2 1
7
7
3) HDCP Link Port3
6) IR Cable In
9) RJ-45 In
5
