SAFETY ADVICE

• Please read through the mounting instructions carefully
before mounting in the bathroom.
• The mounting must only be done by experts.
• Warning: defective mounting is dangerous!
• Check whether the wall is suitable for the mounting and
that the fasteners are strong enough for the forces involved.
• The enclosed fastening material is only suitable for solid
walls of sufficient load-bearing strength.
• In the case of different wall conditions (e.g., plasterboard or
lightweight walls), a different attachment must be made by
the customer which is appropriate to the load.
• Electrical installations should only be carried out by a
specialist electrician DIN VDE 0100-701 (VDE 0100-701):2008-10.
• Electrified, mirrored cabinets and flat mirrors must be locat-
ed at a minimum distance of 600 mm away from the bath or
shower.
• The safety regulations and standards of the particular coun-
tries must be observed.
IMPORTANT INFORMATION
v
• Inspect the packaging for external damage when it is delivered.
• Please check the number of bathroom cabinets supplied and
the associated sets of ironmongery (screws, cover caps,
handles, etc.) against the delivery note or the article's label
on the packaging.
• Caution: only remove the protective caps on the mirrored
cabinet's doors after mounting the doors, in order to avoid
damaging edges of the mirrors.
• Use suitable spacers or distance blocks to even out the
existing differences in level caused by coverings applied to
the walls, e.g., partial tiling.
• Reinforce any walls of insufficient load-bearing strength.
• The drilled dimensions are measured from the FFL according
to the dimensioned layout.
• Fasten the cabinets with the suspension rails:
- Washstand base cabinet
- Vanity unit with drawer
• Always fasten the hanging bar to the wall with 2 screws!
• The horizontal spacing between the cabinets can be chosen
freely.
• Do not tighten water tap and sink pop-up too firmly.
• Pay attention to the assembly and installation instructions
(additionally enclosed).
TOOLS
• Drill and battery-operated screwdriver
• Stone drill bit of 8 mm dia.
• Wood drill bit of 4 mm dia.
• Folding metre rule and measuring tape
• Spirit level
• Screwdriver with a 3.5 mm tip for Phillips screws
• 4 mm Allen key
• Screw clamps
• Pencil
• Silicone sealant (transparent and solvent-free)
Fine Line

MAINTENANCE INSTRUCTIONS

• Caution: do not use any chemicals, aggressive detergent
paste or scouring powder.
• The best way of cleaning the cabinet is to use a damp cloth
with some mild washing-up liquid.
• Take care that no residue from droplets remains on the lower
edge of bathroom cabinets.
• Polish the mirror with a damp cloth or chamois leather.
• The washbasin can be easily cleaned with any of the usual,
non-abrasive cleaning agents.
• Ventilate regularly in order to prevent the mould from forming.
KEEP THE INSTRUCTIONS IN A SAFE PLACE
i
Caution: keep the instructions safely because they contain
information about installing and operating the products!

MOUNTING SEQUENCE

i
For the figures, see the attachment
1. Remove the doors and drawers (Fig. A/A1)
2. Mount the lamps (Fig. B/B1)
The mains wire should not be live!
3. Hang up the furniture (Fig. C/C1/C2/C3)
٠ Mirrored cabinet or flat mirror(centre of the mirrored
cabinet = centre of the water supply connection)
٠ Tall cabinets, Upper cabinets, centre cabinets, High board
٠ Washstand base cabinet
٠ Washstand (centre of the washstand base cabinet = centre
of the water supply connection)
٠ Base cabinets
٠ Plug-in board
٠ Washstand
Pay attention to different heights!
6. Align furniture (Fig. D/D1/D2/D3/D4)
7. Mount the washstand
٠ Put on the washstand (Fig. E)
٠ Seal the washstand (Fig. E1)
8. Install the tap (Fig. F)
٠ Warning: Use the enclosed rubber seal.
٠ Do not overtighten the tap!
9. Screw on the shelf (Fig. G/G1)
٠ Warning: Do not drill through the shelf!
٠ Use the enclosed screws.
10. Mount the doors and drawers (Fig.H/H1/H2)
11. Aligning the doors (Fig. I/I1/I2)
12. Adjusting the drawer (Fig. J/J1/J2)
Important: Loosen the existing connection bracket!
13. Mount the mirror grip (Fig. K/K1)
14. Adjusting the drawer (Fig. L)
