SAFETY ADVICE

• The mounting must only be done by experts.
• Warning: defective mounting is dangerous!
• Check whether the wall is suitable for the mounting and
that the fasteners are strong enough for the forces involved.
• Please read through the mounting instructions carefully
before mounting in the bathroom.
• The enclosed fastening material is only suitable for solid
walls of sufficient load-bearing strength.
• Electrical installations should only be carried out by a
specialist electrician DIN VDE 0100-701 (VDE 0100-701):2008-10.
• Electrified, mirrored cabinets and flat mirrors must be locat-
ed at a minimum distance of 600 mm away from the bath or
shower.
• The safety regulations and standards of the particular coun-
tries must be observed.
IMPORTANT INFORMATION
• Inspect the packaging for external damage when it is delivered.
• Please check the number of bathroom cabinets supplied and
the associated sets of ironmongery (screws, cover caps,
handles, etc.) against the delivery note or the articleʼs label
on the packaging.
• Caution: only remove the protective caps on the mirrored
cabinetʼs doors after mounting the doors, in order to avoid
damaging edges of the mirrors.
• Use suitable spacers or distance blocks to even out the
existing differences in level caused by coverings applied to
the walls, e.g., partial tiling.
• Reinforce any walls of insufficient load-bearing strength.
• The drilled dimensions are measured from the FFL according
to the dimensioned layout.
• Fasten the cabinets with the suspension rails:
- Tall cupboard (600 mm width)
- Mirror cabinet
- Washstand base cabinet (with width 700 and 900 mm)
- Washstand base cabinet with double washstand (1400 mm width)
• Always fasten the hanging bar to the wall with 2 screws!
• The horizontal spacing between the cabinets can be chosen
freely.
TOOLS
• Drill and battery-operated screwdriver
• Stone drill bit of 8 mm dia.
• Wood drill bit of 4 mm dia.
• Folding metre rule and measuring tape
• Spirit level
• Screwdriver with a 3.5 mm tip for Phillips screws
• Screw clamps
• Pencil
• Silicone sealant (transparent and solvent-free)

MAINTENANCE INSTRUCTIONS

• Caution: do not use any chemicals, aggressive detergent
paste or scouring powder.
• The best way of cleaning the cabinet is to use a damp cloth
with some mild washing-up liquid.
• Take care that no residue from droplets remains on the lower
edge of bathroom cabinets.
• Polish the mirror with a damp cloth or chamois leather.
• The washbasin can be easily cleaned with any of the usual,
non-abrasive cleaning agents.
KEEP THE INSTRUCTIONS IN A SAFE PLACE
i
Caution: keep the instructions safely because they contain
information about installing and operating the products.

MOUNTING SEQUENCE

i
Illustrations in the appendix
1. Dismantling the doors (Fig. A)
2. Mount mirrored knob (Fig. B)
3. Mounting the lights (Figs. C/C1)
The electrical mains supply cable must be voltage-free!
4. Suspending the cabinets
∙ Mirrored cabinet
(centre of the mirrored cabinet =
centre of the water supply connection)
∙ Centre cabinets, tall cabinets
∙ High board
∙ Washstand base cabinet/Washstand
(centre of the washstand base cabinet =
centre of the water supply connection)
5. Aligning the cabinets (Figs. D/D1)
6. Mount washstand base cabinet using the mounting
strip (Fig. E)
∙ Note: Only with width 700 mm and 1400 mm for
double washstand!
7. Putting on the washstand (Fig. F)
8. Sealing the washstand (Fig. G)
9. Screwing on the shelf (Fig. H)
∙ Caution: do not drill through the shelf!
∙ Use the screws supplied.
10. Mounting the doors (Fig. I)
11. Aligning the doors (Figs. J/J1/J2)
12. Adjusting the drawer (Figs. K/K1/K2)
13. Changing the flourescent tube (Fig. L)
