In this manual, you’ll find a more detailed description of the features of the S phantom, as well as a guided tour through the front and rear panels, step-by-step instructions for using the S phan- tom, and full specifications.
S phantom Front and Rear Panel Layout Front Panel Layout M IC 1 INPUT- XLR balanced input for M IC 2 INPUT- XLR balanced input 1 2 connecting condenser microphone. for connecting condenser micro- phone. 4 8V ON/OFF switch - When 3 pressed in, the LED illuminates indicating the phantom power is Rear Panel Layout...
Operating the S Phantom Setting Up the S phantom The basic procedure for setting up and using your S phantom is simple and takes only a few minutes. Remove all packing materials (save them in case of need for future service) and check to make sure that you remove the supplied DC power adapter.
• Lower your master volume level control. • Now, power-down the S phantom supply by removing the AC adapter. Typical Set-up The diagram on the right shows a typical set-up for a project record- ing studio using the S phantom...
S phantom Wiring Guide Wiring Guide There are several ways to interface the S phantom, depending on your exact set-up. Follow the cable diagrams below for connecting your gear.
S phantom - Introduction et caractéristiques Introduction Merci d'avoir choisi un S phantom de Samson Audio ! Le S phantom est un module d'alimenta- tion fantôme 48 V à deux canaux pouvant alimenter la plupart des micros à condensateur (deux à...
S phantom - Présentation des faces avant et arrière Face avant E ntrée MIC 1 INPUT - Entrée XLR symé- E ntrée MIC 2 INPUT - Entrée XLR 1 2 trique permettant de connecter un micro symétrique permettant de connec- à condensateur. ter un micro à condensateur.
Utilisation du S phantom Configuration du S phantom La configuration du S phantom est très simple et elle ne prend que quelques minutes. Sortez le S phantom et l'adaptateur secteur de l'emballage (conservez-le pour tout retour en atelier). Mise en garde : Placez les réglages de volume de sortie et d'entrée de la console, du système de sonorisation ou de l'enregistreur au minimum AVANT de connecter ou déconnecter les câbles de vos...
Utilisation du S phantom Déconnexion du S phantom Suivez cette procédure pour déconnecter votre S phantom : • Réglez le niveau des entrées servant à connecter le S phantom au minimum. • Placez le réglage de volume général au minimum. • Mettez le S phantom hors tension en déconnectant l'adaptateur secteur.
S phantom - Guide de câblage Guide de câblage Il existe plusieurs façons de configurer le S phantom en fonction de votre application spécifique. Consultez ces schémas avant de connecter vos équipements.
Herzlichen Glückwunsch zum Kauf der S phantom von Samson Audio! Diese 2-Kanal, 48-Volt Phantomspannungsquelle kann fast alle Kondensatormikrofone im Doppelpack mit Spannung versorgen. Die S phantom ist die perfekte Lösung für Anwendungen, bei denen der Einsatz von Kondensatormikrofonen erwünscht ist, aber die verwendeten Mischer, Recorder, PAs oder Verstärker keine Phantomspannung an den Mikrofoneingängen bereitstellen.
S phantom Layout der Vorder- und Rückseite Layout der Vorderseite M IC 1 INPUT - Symmetrischer XLR-Ein- M IC 2 INPUT - Symmetrischer 1 2 gang zum Anschließen von Kondensator- XLR-Eingang zum Anschließen von mikrofonen. Kondensatormikrofonen. 4 8V ON/OFF-Schalter - Bei 3 gedrückter Taste leuchtet die LED und die Phantomspeisung ist eingeschaltet.
S Phantom bedienen S phantom einrichten Die S phantom lässt sich einfach und in wenigen Minuten einrichten. Entfernen Sie das gesamte Verpackungsmaterial (heben Sie es für eine spätere Verwendung gut auf ) und trennen Sie den mitgelieferten DC Netzadapter von der S phantom.
S Phantom bedienen S phantom-Verbindung trennen Gehen Sie schrittweise wie folgt vor, um die Kabelverbindungen des Systems zu trennen. • Drehen Sie die Pegelregler bei den Eingangskanälen, an die die S phantom angeschlossen ist, ganz zurück. • Drehen Sie den Master-Pegelregler zurück. • Schalten Sie dann die S phantom aus, indem Sie den AC-Adapter entfernen.
S phantom Verdrahtungsanleitung Verdrahtungsanleitung Abhängig von Ihrem speziellen Setup gibt es mehrere Möglichkeiten, die S phantom in Ihr System zu integrieren. Gehen Sie beim Anschließen Ihrer Geräte nach den folgenden Kabel- diagrammen vor.
Introducción y características del S phantom Introducción ¡Felicidades y gracias por su compra del S phantom de Samson Audio! El S phantom es una fuente de alimentación fantasma de 48 voltios de dos canales, capaz de pasar voltaje a la mayoría de micrófonos condensadores, con un máximo de dos a la vez.
Distribución del panel frontal y trasero del S phantom Panel frontal M IC 1 INPUT- Entrada en XLR balanceado M IC 2 INPUT- Entrada en XLR 1 2 para la conexión de un micrófono balanceado para la conexión de un condensador. micrófono condensador.
Manejo del S Phantom Configuración del S phantom El proceso básico para la configuración y manejo de su S phantom es muy simple y solo le ocupará unos minutos. Separe todo el embalaje y protecciones (pero consérvelos por si necesita usarlos de nuevo en el futuro) y asegúrese de extraer el adaptador de corriente incluido.
S phantom. • Baje el control de nivel de volumen master. • Ahora, apague el S phantom simplemente desconectando su adaptador de corriente. Configuración típica El diagrama siguiente le muestra una configuración típica para un estudio de grabación de proyectos en el que se usa el S phantom para la conexión de...
Guía de cableado del S phantom Guía de cableado Existen varias formas de interconectar el S phantom, dependiendo de su configuración concreta. Consulte los diagrama de cables siguientes a la hora de conectar su equipo.
PA da usare non dispongono agli ingressi microfonici di alimentazione fantasma. Qualunque sia l'esatta situazione d'uso, l'S phantom è in grado di fornire prestazioni affidabili e di alta qualità, grazie alla solida realizzazione della sua costruzione, basata su di uno chassis in alluminio a estru- sione con piedini in gomma di dimensioni generose.
S phantom - I Pannelli Frontale e Posteriore Pannello Frontale I NGRESSO MIC 1 - ingresso XLR bi- I NGRESSO MIC 2 - ingresso XLR bilan- 1 2 lanciato per il collegamento di micro- ciato per il collegamento di microfoni a foni a condensatore. condensatore.
La Configurazione dell'S Phantom La Configurazione dell'S phantom La procedura di base per la configurazione e l'uso dell'S phantom è semplice e richiede solo pochi minuti. Eliminate tutti i materiali di imballo (conservateli nel caso vi servano in futuro per evenuali spedizioni in assistenza) ed assicuratevi di aver preso fuori l'alimentatore in CC in dotazione.
Abbassate, fino a chiuderli, i controlli di livello dei canali di ingresso ai quali avete collegato l'S phantom. • Abbassate il controllo generale di livello del volume. • A questo punto spegnete l'alimentatore S phantom staccandone l'adattatore in CA. Configurazione Tipica Il diagramma a fianco mostra una configurazione tipica per uno studio di registrazione di...
S phantom - Guida al Cablaggio Guida al Cablaggio È possibile interfacciare l'S phantom in molti modi differenti, a seconda dell'esatta configurazio- ne d'uso. Ecco di seguito i diagrammi per il collegamento delle vostre apparecchiature.
5.65” L x 4.13” W x 2” H (144mm L x 105mm W x 51mm H) Weight 16.5 oz., 419 gm. Specifications are subject to change without notice. S phantom - Caractéristiques techniques Tension d'alimentation fantôme 48 V Connecteurs Entrée Mic 1 XLR symétrique (Broche 1 : Masse, Broche 2 : Plus, Broche 3 :...
144mm L x 105mm B x 51mm H (5.65” L x 4.13” B x 2” H) Gewicht 419 g, 16.5 Unzen Technische Daten können unangekündigt geändert werden. Especificaciones técnicas del S phantom Voltaje de alimentación fantasma 48 voltios Conectores Entrada Mic 1...
