Vehicle Dock Features; Installation Instructions - Intermec AV5 Anleitung

Vehicle Dock Features

1 Mobile device retaining assembly
2
Mobile device holding bay
Docking connector
3
4
Flush mounting option
5
Mounting kit attachment option
6 Serial connector
7 Vehicle power source connector
Installing Mobile Device into Dock

Installation Instructions

To install and use the Vehicle Dock, you need: Intermec Vehicle
Dock Mounting kit (P/N: 805-638-001)
