Eexii-signalwecker

Werbung

pplication
The signalling bell dGW21 was
designed to warn, call and signal in
areas with explosive atmospheres
in group II and rough ambient
conditions. The explosion category
II 2 G EEx de IIC T6
allows
signalling bell to be used in areas
with explosive atmospheres in zone
1 and 2.
The signalling bell produces a
sound volume of approx. 105 dB( )
at 1 meter distance.
The emphasis of the ring lies at
approx. 1000 Hz, as a result of
which the signal stands out clearly
against lower-frequency ambient
noises. The bell is available for all
usual supply voltages. The version
dRGW 21 comprises a telephone
calling relay and reproduces the
signals in the pulse rate of the
overriding telephone call.
Design
Explosion protection is ensured by
the flameproof enclosure of the
driver system and the terminal box
realised in the explo sion protection
mode
"in creased
safety".
flame proof room contains the elec-
tromagnetic driver system and, for
the design dRGW21 an additional
telephone calling relay. The enclo-
sure is made completely of plastic
thus guaranteeing protection from
Technical specification
Enclosure
Colour of enclosure
(Surface resistance)
Insulation class
Protection category
Cable glands
Operating temperature
Storage temperature
Operating mode
Operating utilization position
Operating conditions
Connecting terminals
Sound pressure level
Explosion category
EC-type-examination certificate
Dimensions
Weight
corrosion. In addition we realize
insulation class II, so there is no
equipotential bon ding necessary.
The construction is furthermore
low-weight and very robust. ll d.c.
versions are equipped with an
the
electronic contact breaker which
considerably increases service life
compared with other available
devices.
Recycling
The device can be disposed of
completely as electronic waste.
When the device is disassembled,
plastics, metals and electronics are
to be disposed of separately.
ssembly
The signalling bell is suitable for eit-
her wall or ceiling mounting. Please
refer to page 5 for mounting
dimensions. ll fixing elements and
bases must bear the weight of the
device (approx. 3.5 kg). Please
assemble the wall fixtures, which
are part of the scope of delivery,
(including assembly material) and
arrester plate according to Figure 1
on page 5. Make sure the catches
The
of the safety plate fit in the ope-
nings in the wall bracket.
Connecting and adjusting
The device may only be connected
and adjusted by qualified personnel.
The regulations and instructions of
Fiberglass reinforced polyester
grey or black in electrostatic conducting enclosures (R ≤10
Optionally black or blue or yellow for non-conducting enclosures (R ≥10
II (no potential bonding necessary).
IP 66 (acc. IEC 529/EN 60529)
1x M20 x 1.5 and vent plugs M20 x 1.5
optionally 2x cable entry M20 x 1.5 for design dRGW21
-20°C bis +40°C
-20°C bis +80°C
Continuous operation as per IEC34; DIN EN 60034-1; VDE 0530 Level S1
Bell dome to the front (tappet downwards)
Inside or outside
1.5 mm
2
stranded wire
2.5 mm
2
solid wire
approx.105 dB( ) at 1 meter distance
II 2 G EEx de IIC T6
PTB 01 TEX 1064
pprox. 210 x 190 x 190 mm
pprox. 3.5 kg
the respective country regarding
connection to the public telephone
network and/or to private branch
exchanges (PBX) have to be con -
sidered. The following regulations
concerning connection and adjust-
ment
are
to
be
Regulations regarding connection
to the mains must also be obser-
ved. Mains connection at terminals
1 and 4. Connection to other
devices at terminals 2 and 3 (see
Fig. 2 on page 5). When using the
telephone calling relay connect
mains to terminals 1 and 2 and the
telephone connection to terminals
3 and 4 (see Fig. 3 on page 5).
Remarks
Each signalling bell is adjusted in
the works. Should the sound alter
after a certain number of operating
hours, a qualified person can adjust
the tappet in the device as follows:
• pply rated voltage
• Push the bell system higher after
unscrewing the system fixing
screws until the sound is optimal
• Replace the system fixing screws
and tighten
Warning:
The device has a very loud sound
volume. To avoid damage to the
hearing, do not come too close to
the sound emitter.
9
)
observed.
9
)
