EN
Intended use
As a mirror with dimmable lighting and heating for use in
wet rooms such as bathrooms and toilets.
The product is suitable only for mounting indoors!
Caution! Only install in frost-free rooms.
Declaration of conformity! This product complies with
the requirements of the valid EU Guidelines. The dec-
laration of conformity for this product can be requested
from the following address:
KEUCO GmbH & Co. KG, Oesestraße 36,
D-58675 Hemer.
Technical data
– Power supply:
– max. Power consumption:
Prod. no.:
33296 XX1000: 460 mm
– Protection rating:
– Ambient conditions:
Temperature
– Light colour
Mounting dimensions, see page 2.
Circuit diagram, see fi gure 1 on page 17.
The device can be operated in two modes.
Mode 1 (ex works):
Lighting On/Off at the device button (Off automatically
after power returns).
Mode 2:
Lighting On/Off at the external light switch (Off
automatically after power returns).
Installation, see fi gure 2 onwards on page 17.
Important information, please make sure to read!
230 V AC/ 50 Hz
Width Weight
9.9 kg
3000 Kelvin
Operation

Button Function

Light on/off
• Pressing the button switches the mirror on with the
• Pressing the button again switches the mirror off .
To change mode
• Switch off the refl ector.
• Press the button and hold it down for 15 seconds.
Repeat the procedure described to re-enable mode 1.
• The white LED can be deactivated.
– Switch on the mirror.
– Press and hold the button for 10 seconds.
Light
18 W
IP20
5°– 40° C
To switch the white LED back on, repeat the de-
scribed procedure.
Front and wall lighting
• The front and wall lighting is switched on by press-
• Pressing the button again switches the light off .
Washbasin lighting
• The washbasin lighting is switched on by pressing
• Pressing the button again switches the light off .
When both lightings are switched off , the mirror also
switches off .
Dimming the front, wall and washbasin lighting
• Press the button when the mirror is switched on
The setting is stored and reproduced when switched
on again (only for connection type 1, see fi gure 1 on
page 17).
Replacement parts with order numbers, see pages 19.
The light sources may only be replaced by the
manufacturer, its customer service or by an equally
qualifi ed person.
For information about warranty and maintenance, see
the enclosed Maintenance and Warranty Passport.
Disposal information! Equipment with this labelling
must not be disposed of in household refuse, but must
be disposed of at a collection centre intended for this
purpose.
selected settings. The white LED goes off .
The white LED lights up.
- A short light impulse indicates that the mode
has been changed.
- The lighting goes off .
- A short light impulse indicates that the white
LED was deactivated.
ing the button when mirror is switched on.
the button when mirror is switched on.
and hold until the desired brightness or the end
value has been reached.
