fEATURES
• Full duplex communication
• DSP filter (digital cancellation of echo and background noise)
• Communicates up to 500 meters (in an open field)
• Automatic volume adjustment (according to speed and
background noise)
• Lithium battery
• Talk time: up to 10 hours
• Standby time: up to 700 hours
• Charging time: 3 hours
• Dimensions: 90 x 46 x 20 (mm)
• Weight of module: 42 g
• Weight of speaker: 150 g, including cable and aluminium
bracket

NOTES ON pERfORMANCE

During intercom communication, one of the two INTERPHO-
NE units draws more from its battery . This is due to the wi-
reless search procedure that the module in question carries
out in order to stay connected to the other module, which
may lead to a difference in autonomy of 60-90 minutes .

pRODUCT DESCRIpTION

bluetooth® module
1 . MFB (multifunction button)
2 . Speaker/microphone jack
3 . VOLUME + button
4 . VOLUME - button
5 . LED indicator light
6 . Pins for mounting module on bracket
Mounting bracket for bluetooth® module
7 . Cable clasp
8 . Snap-on guides for module
9 . Magnets
10 . Metal mounting clip
Speaker
11 . Speaker unit
12 . Connector with microphone
13 . Velcro with bi-adhesive strip
14 14
14 . Speaker cable with 3 .5 mm jack plug and microphone
pACK CONTENTS
• Bluetooth® module
• Plastic mounting bracket with magnet
• Metal sun visor clip
• Speaker with microphone
• Cable with microphone and 3 .5 mm jack plug
• Mains battery charger
1 fIRST USE
1.1 Charging
The INTERpHONE CAR KIT must be charged before use .
Connect the battery charger to a 110-220V socket and insert the
charge plug into the INTERpHONE CAR KIT charging socket .
The LED indicator light turns red during charging .
When the unit is fully charged, the LED will turn green .
1.2 Installation
MOUNTING THE MODULE
After installing the bracket on the Bluetooth® module (with
the side containing the magnets facing outwards), grasp the
module and insert it downwards into the guide .
Check that the Bluetooth® module is correctly locked into
position by trying to pull it upwards and out .
Place the metal clip on the sun visor and mount the module
using the magnets on the bracket .
CONNECTING THE MODULE TO THE SPEAKER
After mounting the module on the sun visor, place the spea-
ker in the desired position inside the car . Use the Velcro with
bi-adhesive strip, or use the mounting bracket .
After the speaker has been positioned, insert the jack plug
into the jack at the bottom of the module .
NOTE: For best conversation quality, it's a good idea to
mount the speaker inside the car at a minimum distance of
60 cm from the module .
USING THE CABLE WITH 3 .5 MM JACK PLUG
If the stereo system in your car has a 3 .5 mm AUX jack, the
system can be used to listen to intercom conversations .
Insert the 3 .5 mm jack plug on the cable provided with the
unit into the AUX input jack in the car, plug the connector
into the speaker/microphone socket and, if necessary, set
the stereo system to play from the AUX input .
