- Seite 1 QUICK INSTALLATION GUIDE Talos M I D - T O W E R P C C A S E...
-
Seite 2: Inhaltsverzeichnis
TABLE OF CONTENTS 1 Specifications 2 Exploded View & Parts 3 Accessory 4 Side Panel Removal 5 Motherboard Installation 6 PSU Installation 7 3.5" & 2.5" HDD Installation 8 PCI-E / PCI Card(S) Usage 9 Air Cooling Compatibility 10 Radiator Compatibility 11 I/O Ports 12 I/O Connectors 13 RGB Fan Controller Installation... -
Seite 3: Specifications
SPECIFICATIONS Model Name TALOS P1 Dimensions (H x W x D ) 481 x 215 x 550 mm 18.9 x 8.5 x 21.7 inch Case Type MID Tower Material(s) Tempered Glass, SPCC, ABS Side Panel 4mm Tempered Glass x 4 (Left &... -
Seite 4: Accessory
EXPLODED VIEW PARTS PARTS Chassis Body Front Panel Swing Door IO Port Tempered Glass Side Panel Logo Panel Tempered Glass Top Panel HDD Tray Tempered Glass Front Panel Rubber Foot Top Panel ACCESSORY Parts Name Used for Figure Stand-off #32 x 6 mm Motherboard Screw #6 x 6 mm Screw #6 x 5 mm... -
Seite 5: Side Panel Removal
SIDE PANEL REMOVAL English Português Remove the side panel Remova o painel lateral Español Русский Retire el panel lateral Снимите боковую панель Deutsch Türk dili Seitenblende entfernen Yan paneli çıkarın Polski 日本語 サイドパネルを取り外します Usuń panel boczny Français 한국어 Retirez le panneau latéral 사이드... -
Seite 6: Motherboard Installation
MOTHERBOARD INSTALLATION English Português Lay down the chassis Deite o chassi Install the motherboard in proper location Instale a placa-mãe no local correto e and secure it with screws prenda-a com parafusos Español Русский Tumbe el chasis Снимите подставку Instale la placa base en la posición adecuada Установите... -
Seite 7: Psu Installation
PSU INSTALLATION English Português Place the PSU in proper location Coloque a PSU no local adequado Español Русский Coloque la PSU en la posición adecuada Поместите блок питания в нужное место Deutsch Türk dili Netzteil an der richtigen Stelle platzieren PSU’yu uygun konuma yerleştirin Polski 日本語... -
Seite 8: " 2.5" Hdd Installation
3.5" 2.5" HDD INSTALLATION 3.5" HDD 2.5" SSD English Português A. 3.5" HDD A. HDD 3.5" Align the HDD into the mounting holes and screw in. Alinhe o HDD nos orifícios de montagem e aperte-o. B. 2.5" SSD B. HDD 2.5" Align the SSD into the mounting holes and screw in. -
Seite 9: Pci-E / Pci Card(S) Usage
PCI-E / PCI CARD (s) USAGE English Português (Optional) Extend in stalling to Motherboard. (Opcional) Estenda a instalação à placa-mãe. PCI-E Cable Not Included. Cabo PCI-E não incluído. Español Русский (Opcional) Instalación en placa base. (Дополнительно) Расширенная установка на Cable PCI-E. системной... -
Seite 10: Air Cooling Compatibility
AIR COOLING COMPATIBILITY English Svensk 日本語 上部120 mm x 3または140 mm x2 Top 120 mm x 3 or 140 mm x2 Ovansida 120 mm x 3 eller 140 mm x2 Front 120 mm x 3 or 140 mm x2 前部120 mm x 3または140 mm x2 Framsida 120 mm x 3 eller 140 mm x2 Rear 120 mm x 1 Baksida 120 mm x 1... -
Seite 11: Radiator Compatibility
RADIATOR COMPATIBILITY English Svensk 日本語 上部 360 mm または 280 mm Top 360 mm or 280 mm Ovansida 360 mm eller 280 mm Front 360 mm or 280 mm 前部 360 mm または 280 mm Framsida 360 mm eller 280 mm Rear 120 mm Baksida 120 mm 後部... -
Seite 12: I/O Ports
I/O PORTS Power Button Headphone Speed Controller USB 2.0 Fan LED Control USB 3.0 English Svensk 日本語 切り替え可能IOとロゴプレート Switchable IO and Logo Plate IO som kan sättas på och stängas av och logotypskylt Español Italiano 한국어 E/S conmutable y placa de logo IO commutabile e piastra logo 스위치블... -
Seite 13: I/O Connectors
I/O CONNECTORS USB 3.0 POWER POWER POWER HD AUDIO LED+ LED- English Português See your motherboard's manual for front panel header Veja o manual da sua placa-mãe para localizar locations and pi-outs. os locais e os compartimentos do painel frontal. Español Русский... -
Seite 14: Rgb Fan Controller Installation
RGB FAN CONTROLLER INSTALLATION English ◆ The Fan Led wiring must be connected to the fan hub in the order you want the lighting effects to be displayed. ◆ Fans must start at "1" and continue in series. 1 > 2 > 3 > 4 > 5 > 6 ◆... - Seite 15 RGB FAN CONTROLLER INSTALLATION Polski ◆ Okablowanie LED wentylatora należy podłączyć do koncentratora wentylatora w odpowiedniej kolejności, aby uzyskać wyświetlanie żądanych efektów oświetlenia ◆ Wentylatory muszą uruchamiać się przy „1” i kontynuować działanie szeregowo. 1 > 2 > 3 > 4 > 5 > 6 ◆...
- Seite 16 RGB FAN CONTROLLER INSTALLATION Italiano ◆ Il cablaggio del LED ventola deve essere collegato al mozzo della ventola nell'ordine in cui si desidera visualizzare gli effetti luminosi ◆ Le ventole devono partire da "1" e continuare in serie. 1 > 2 > 3 > 4 > 5 > 6 ◆...
- Seite 17 RGB FAN CONTROLLER INSTALLATION Türk dili ◆ Fan LED’i tesisatı, aydınlatma efektlerinin görüntülenmesini istediğiniz sırayla fan göbeğine bağlanmalıdır ◆ Fanlar "1" değerinden başlamalı ve sıralı olarak devam etmelidir. 1 > 2 > 3 > 4 > 5 > 6 ◆ Sıralı olarak bağlanmayan herhangi bir fan iletişimi kesecek ve RGB aydınlatma işlevi çalışmayacaktır ◆...
- Seite 18 RGB FAN CONTROLLER INSTALLATION ภาษาไทย คุ ณ ต้ อ งเสี ย บสายไฟ LED ของพั ด ลมกั บ ดุ ม พั ด ลม เอฟเฟ็ ก ต์ แ สงสว่ า งต่ า งๆ ถึ ง จะปรากฏที ่ พ ั ด ลม ◆ พั...
