General safety precautions
This installation manual is intended for qualified personnel only.
Read the instructions carefully before beginning to install the
product. Incorrect installation may be a source of danger.
Packaging materials (plastics, polystyrene, etc) must not be allowed to
litter the environment and must be kept out of the reach of children for
whom they may be a source of danger.
Before beginning the installation check that the product is in perfect
condition. For repairs or replacements of products only original spare
parts must be used.
EC declaration of conformity
The manufacturer Entrematic Group AB, with headquarters in
Lodjursgatan 10, SE-261 44 Landskrona, Sweden, declares that
operated access control sytem is in conformity with the provisions of the
following EC directives:
RED Directive 2014/53/EU;
EMC Directive 2014/30/EC;
Landskrona, 2018-04-02
1. Technical data
Power supply
Absorption
Output N.O. (OUT1)
Temperature
Degree of protection
Operation frequency
Memory capacity
Range
Reader and control unit
connection [70 m with 2 AXR7]
Dimensions
2. Reference
[1] AXR7 signalling LED
[2] Selecting dip-switches
[3] Full code deletion key
[4] LAN7S signalling LED
[5] Code learning key
[6] Serial line connector RS-485
[7] Memory module
3. AXR7 installation
The fastening can be made directly on the wall (Fig. 2), or using the
special columns (Fig. 3).
- Secure the AXR7 reader in its envisaged position of use.
- Connect the card AXR7 to the LAN7S control unit by means of a
burglarproof-type screened cable (not supplied) as shown in fig. 6
(taking care to connect the screening to the earth terminal).
Note: two AXR7 reading units can be connected in parallel.
- Selecting the DIP SWITCH [2] mode:
With DIP=ON, LED [1] comes on only if read code has been given
access authorisation.
With DIP=OFF, LED [1] comes on whenever any code is read.
4. LAN7S installation
- Insert the LAN7S control unit in the relative housing for AUX plug-in
cards (alternatively, use the CONT1 support).
- Link up the LAN7S control unit to the AXR7 reader as described in
fig. 6.
- Power on. LED [4] may rapidly flash for 15 to 20 seconds during the
initialization phase.
4.1 Codes storing
- Press LEARN key [5]. LED [4] will light on.
Matteo Fino
(President & CEO)
AXR7 LAN7S
/ 24 V
/ 100 mA÷200 mA
/ 24 V= / 1 A (1 s)
-20° C / +55° C
IP44 /
125 kHz /
/ 508 codes
60 mm [LAN7B]
/
30 mm [LAN7K]
max 100 m
/
(see Fig. 1) 100x50x16
The learning mode will remain active for about 60 s.
Bring a LAN7B card or LAN7K token close up to the AXR7 reader
(Fig. 4) to allow the reader to memorize the code on memory mo-
dule [7].
After each reading, learning mode time count is reset to 10 s.
- LED [4] flashes twice upon each code being stored (up to 508 codes
can be stored). After storage of each code has been completed, the
LAN7S goes into stand-by for 10 s. If no further code is read within
this time, the LAN7S automatically exits from the learning mode.
Note: if the code read by the AXR7 reader has already been stored,
LED [4] rapidly flashes and the code is automatically disregarded.
Note: it is possible to increase the memory capacity up to 1016
codes by connecting two LAN7S boards as shown in fig. 7. In this
case, memorise some of the codes on one of the LAN7S cards, and
the rest on the other card. To optimise the response times, you are
AXR7
advised to memorise roughly half the required codes on each card.
- Exiting from the learning function will occur automatically 60 s.
after last memorisation or by pressing the LEARN key again.
4.2 Delete all codes
- To delete all codes from memory module [7], first press ERASE key
[3] and keep pressed for 3 seconds. Upon key [3] being released,
LED [4] will slowly flash for 5 s. At this point, press ERASE key [3]
again before these 5 s. have elapsed to definitely confirm deletion of
all previously stored codes. While deletion is underway, LED [4] will
rapidly flash.
Note: it is not possible to delete a single code.
Note: if LAN7S breaks down, the same memory module [7] can be
installed on another control unit. This avoids having to re-codify all
the codes. Remove and insert the memory with LAN7S powered-off.
- Alarm. Should an internal alarm be detected, the LAN7S goes into
alarm state, which is signalled by LED [4] flashing quickly.
5. Operating
After having stored all codes, bring the LAN7B card or LAN7K token
close up to the AXR7 reader (Fig. 4) to activate automatic door or gate
opening.
The crossed-out wheeled bin symbol indicates that the product
should be disposed of separately from household waste. The
product should be handed in for recycling in accordance with lo-
cal environmental regulations for waste disposal. By separating a mar-
ked item from household waste, you will help reduce the volume of
waste sent to incinerators or landfill and minimize any potential nega-
tive impact on human health and the environment.
