CONNECTION TO PS3/XBOX 360
VIDEO
INPUT
1] Connect the RCA cable to your chosen VIDEO INPUT source (A).
2] Connect the red and white ends of the RCA cable (not included,
but usually provided with your game console) into the corresponding
ports of the RCA adapter (B).
3] Connect one end of the mini audio cable into the RCA adapter (C) and the
other end into the INPUT socket on the control panel (D).
If you have a HDMI Cable connected:
PS3 : The PS3 settings need to be changed as follows : Settings > Sound
Settings > Audio Output Settings then choose Audio Input Connector/
Scart / AV Multi.
Xbox 360 : An AV RCA adaptor is required (to enable simultaneous use of
both the HDMI and AV RCA ports).
CONNECTION TO PS4
Option 1
Option 1 :
1] Connect the audio cable supplied with the RC-1 to the PS4 controller.
2] Go to Settings > Device Settings > Audio Device Settings and set the
Output to 'All Audio'.
3] Adjust the sound settings and click OK before leaving these settings.
Option 2 :
1] Connect the audio cable supplied with the RC-1 to the headphone socket
on your TV/Monitor.
2] Go to Settings > Devices > Audio Devices and set Output to 'Chat Only'
3] Adjust the sound settings and click OK before leaving these settings.
3
(NOT INCLUDED)
Option 2
