look 986 Montageanleitung Seite 23

GB
2/ Insertion of the E-Post into
the frame
1 – Make sure the bolt in the E-Post is
loosened (the elastic rings expander should
not be flanged but the screw should remain
in place).
2 – Height adjustment (possible 0 to 32.5
mm, every 1.25 mm): select the combination
of spacers among the 6 supplied (see table
on opposite page recapitulating all the
possibilities), and mount them under the
rod's shoulder.
Keep at least one support washer. The other
spacers follow according to the desired
adjustment height.
3 - Insert the E-Post in the saddle tube and
bring it at the stop at the top of the joint.
4 – Tighten the rod screw (4 mm hex key, at
the torque of 5 Nm). (Photo 5)
22
Support
washer
Elastomer
Maxi : 5 Nm.
Photo 5
