1) Carefully unpack the product.
2) Hold the product upright and slightly open the tripod legs (1) for increased stability during installation.
3) Press the tension knob (5) and extend the extension tube (2) until it clicks into place.
4) Put the screen housing (7) in a horizontal position with the screen facing upwards.
5) Now carefully pull the screen upwards holding on to the hanging string (8). To ensure a flexible adjustment of
the inclination angle of the screen, you can attach the hanging string to one of three indentations.
6) Lift the construction and fully open the tripod legs (1).
7) You can now adjust the screen height using the tension knob (5). Ideally, use both hands for this procedure:
Firmly hold the extension tube (2) with one hand to keep it from dropping too fast and press the tension knob
with the other hand.

DESCRIPTION OF PARTS

Tripod
Extension tube
Handle
Locking knob
Tension knob
Screen
Screen housing
Hanging strip
Latch for screen housing

SETUP
