HMDX Stream Handbuch

CAN'T FIND THE INSTRUCTIONS IN YOUR LANGUAGE?
Please visit www.hmdxjam.com
UK HMDX Stream
Thank you for purchasing the HMDX Stream Wireless Stereo Speaker.
Please read these instructions and keep them for easy reference.
Getting started
Unpack the unit carefully. Remove all the accessories from the display carton.
Do not remove any labels or stickers on the rear of the unit and adaptor. Before
setting up the unit, verify that the following accessories are present:
• Instruction manual x 1
• Main unit x 1
• AC power adapter x 1
• 3.5mm aux-in cable x 1
Power Source
This unit is supplied with an AC adapter; take the following steps to connect the
adapter.
1. Connect the DC plug of the AC adapter to the DC socket on the rear of the unit.
2. Plug the AC adapter to the AC outlet (220v-240v). Connecting this system to
any other power source may cause damage to the system.
3. To switch the unit off completely, withdraw the AC adapter from the wall outlet
and remove batteries from product.
Battery operation
• Before installing batteries (not included), ensure that the unit is disconnected
from the main power supply.
• Remove the battery compartment cover on the back of the unit by carefully
pushing off the battery cover.
• Insert 4 AA size batteries(not included), referring to the polarity markings
inside the battery compartment. Never mix old and new batteries.
• Replace the cover.
• For battery operation, switch off the main supply and remove the cable from
the power socket, battery operation will be selected automatically.
Battery precautions
• Use only the size and type of batteries specified.
• When installing batteries, observe proper +/- polarities. Incorrect installation
of battery may cause damage to the unit.
• If the unit is not going to be used for a long period of time, remove batteries to
prevent damage due to possible battery leakage.
• Do not dispose of batteries in fire. Batteries may explode or leak.
• Remove used batteries promptly.
• Do not use alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-MH,
etc.) batteries
• Clean the battery contacts and also those of the device prior to battery
installation.
This product contains small parts that may present a choking hazard for young
children.
Listening to your device wirelessly over bluetooth®
To listen to your music over Bluetooth® wireless connection, you need to pair your
device with HDMX Stream:
1. Make sure your device has Bluetooth® capability.
2. Press the POWER button to turn on the unit. The Bluetooth® light will flash
slowly after 5 seconds.
3. Once the Bluetooth® button beings to flash, press and HOLD the Bluetooth®
button for a few seconds until the Bluetooth® light begins to flash quickly.
4. Follow the instructions of your device to pair the unit.
5. Pair your device with the unit by selecting Stream from your Bluetooth®
listings on your device or selecting YES.
6. Press play on your device and use controls on the unit or remote to adjust to
desired volume.
7. The effective range of the Stream is approximately 30-feet from the
Bluetooth® device. Range can be affected by numerous factors including
the Bluetooth® device, wall materials, etc. If you experience audio drop outs
please move the Bluetooth® device closer to the Stream.
NOTE: Once you have successfully paired your device, you typically will not need
to repeat the above steps. Please ensure the AUX cable is unplugged, the unit
source is set to Bluetooth® and your device has Bluetooth® enabled.
NOTE: When pairing with a computer, please consult your computer manufacturer
for Bluetooth® pairing instructions and/or the latest Bluetooth® Drivers. A pairing
code is not required.
Listening to your device through the auxiliary aux audio jack
1. Connect the supplied audio cable to the headphone or line-out jack of an
audio device and plug the other end of the cable into the AUX In Audio jack on
the back of the unit.
2. Press the POWER button to turn on the unit.
3. Press PLAY on the device and use controls on the unit to adjust to desired
volume.
NOTE: PLAY/PAUSE controls on Stream will not work when using Line-In Audio Jack.
Stream Wireless Stereo Speaker
(Fig. 1)
1. Speaker Phone Button 4. Volume Controls
2. Bluetooth® Button 5. Power Button
3. Play/Pause Button
(Fig. 2)
1 2 3
Hands free speakerphone
The Stream can be used as a Hands-Free Speakerphone. When using the
speakerphone make sure to talk directly at the front of the product. The built-in
microphone will only work when it is connected to a Bluetooth® enabled device.
Answer/end a call
Press the PHONE button to answer and end a call.
Decline an incoming call
Hold the PHONE Button for 2 seconds.
Make a call
Use your phone to dial. Call will play over speakers (make sure phone is paired
to speaker).
USB charging port
• The USB port is for charging only. It cannot be used to play music through the
unit.
• In order to use the USB charging feature, you must have the proper cord to
connect to your device with a USB connector on the other end.
To charge your device using the USB charging port (located on the back of the unit):
1. Connect the USB type A end of the device's cable into the USB port on the rear
of the Stream.
2. Connect the other end of the USB cable to your device to begin charging.
Using the universal dock
Place tablet or smartphone in the dock.
Maintenance
To store
You may leave the speaker on display, or you can store it in its box in a cool, dry
place.
To clean
Only use a soft dry cloth to clean the enclosure of the unit.
NEVER use liquids or abrasive cleaner to clean.
READ ALL INSTRUCTIONS BEFORE USE AND SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE. IMPORTANT SAFEGUARDS: WHEN USING ELECTRICAL
PRODUCTS, ESPECIALLY WHEN CHILDREN ARE PRESENT, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
• WARNING: Do not place speakers too close to ears. May cause damage to ear
drums, especially in young children.
1
1 2 3 4 5
1. USB Port
4
2. DC IN
3. AUX IN
4. Battery Compartment
