5. USING METHOD
5.1 PAPER LOADING
1.
Use two fingers to press the place showed in the above picture and open the top cover.
2.
Put the paper roll into the paper case, pay attention to the direction of paper. If loaded reversely, it won't print.
3.
Pull paper out of paper case.
4.
Make sure paper in the center then closed top cover.
5.2 BASIC FUNCTION USING
5.2.1 TURN ON
Under the close state, press [POWER] button 2 seconds, the printer enters to the working state, the power indicator light (Red).
5.2.2 TURN OFF
Opening state, press [POWER] button 2 seconds, the printer will be closed, all the indicator light will be off.
5.2.3 INSPECT ITSELF
The user can inspect the printer by themselve after getting the printer, to check the current state and setting.
Inspect method: turn-off. Hold [FEED] button, and then press [POWER] button the printer will print out the inspect page, the inspect page
including the current state, setting, example of printer.
5.2.4 PAPER FEEDING
Under the usual working state, press [FEED] button, start to feed paper.
USER'S MANUAL IMP05
Rubber Roller
Top cover
Use two fingers to press this place
and open the top cover
Thermal paper roller
EN
25
