Technical Specifications - Samoa 366 000 Bedienungsanleitung

Type
Functions
Moist part materials
Inlet connection
Outlet connection
Maximum working pressure
Burst pressure
Compatible fluids
Flow
Viscosity range
Operating temperature
Precision
Display
Measurement units
Display dimensions
Display view angle
Display resolution
Power supply
Consumption
Pulse ratio
Pushbutton actuation force
Weight
Dimensions
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: +34 985 381 488 · www.samoaindustrial.com

Technical Specifications

Oval gear meter.
Partial meter, "Trip" meter, Total meter, change in the measu-
rement unit, calibration.
Aluminium, LCP, NBR, Stainless Steel.
1/2" BSP and flange.
1/2" BSP and flange with seating for O-ring.
100 bar.
150 bar.
Oil, glycol and coolant solutions.
1 to 30 l/min (depending on the viscosity of the fluid and
temperature).
8 a 2000 cSt.
-10 ºC a 60 ºC.
±0,5%.
LCD with 5 digits and 2 decimal positions.
Litres, gallons, quarters, pints.
20 x 41,5 mm.
170º.
0,01 for litre, gallon and quarter units.
0,02 for pint units.
Two 1,5 V batteries, IEC LR03 / ANSI AAA.
Rated operation: 1 mA.
Standby mode: 10 µA.
164 ppl.
160 gr.
535 gr.
7
R. 09/14 836 826
