4.8.3 Select a transform switch accordingly for the item to be measured.
4.8.4 When connection, first connect to the public testing line, then to the electriferous testing line. When you'll
remove it, you should remove the elecriferous one.
4.9 DC VOLTAGE MEASURING
You can't input the voltage which more than 600V DC, it's possible to
Pay attention not to get an electric shock when measuring high voltage.
4.9.1 Connect the black test lead to the COM jack and the red test lead to the V jack.
4.9.2 Set the transform switch at the V range position.
4.9.3 Put down the "FUNC." to enter the DC measurement. Auto range or manual range can be transformed by
putting the "RANGE".
4.9.4 Connect test leads across the source or load under measurement.
4.9.5 You can get reading from LCD. The polarity of the red lead connection will be indicated along with the voltage
value.
NOTE:
• When only the figure 'OL' is displayed, it indicates overrange situation and the higher range has to be selected.
• When the value scale to be measured is unknown beforehand, set the range selector at the highest position.
4.10 AC VOLTAGE MEASURING
You can't input the voltage which more than 600V rms AC, it's possible
Pay attention not to get an electric shock when measuring high voltage.
4.10.1 Connect the black test lead to the COM jack and the red test lead to the V jack.
4.10.2 Set the transform switch at the V range position.
4.10.3 Put down the "FUNC." to enter the AC measurement. Auto range or manual range can be transformed by
putting the "RANGE".
4.10.4 Connect test leads across the source or load under measurement.
4.10.5 You can get reading from LCD.
NOTE:
• When only the figure 'OL' is displayed, it indicates overrange situation and the higher range has to be selected.
• When the value scale to be measured is unknown
4.11 DC CURRENT MEASURING
Shut down the power of the tested circuit, then connect the meter with
4.11.1 Connect the black test lead to the COM jack and the red test lead to the mA jack for a maximum of 400mA
current. For a maximum of 10A, move the red lead to the 10A jack.
4.11.2 Set the transform switch at the desired A range position.
4.11.3 Put down the "FUNC." to enter the DC measurement. At mA range, auto range or manual range can be
transformed by putting the "RANGE".
4.11.4 Connect test leads in series with the load under measurement.
4.11.5 You can get reading from LCD. The polarity of red connection will be indicated along with the voltage value.
NOTE:
• When only the figure 'OL' is displayed, it indicates over range situation and the higher range has to be selected.
• When the value scale to be measured is unknown beforehand, set the range selector at the highest position.
• "
" means the maximum current of mA socket is 400mA, the maximum current of 10A socket is 10A, over-current
will destroy the fuse.
show higher voltage, but it's may destroy the inner circuit.
to show higher voltage, but it's may destroy the inner circuit.
the circuit for measurement.
WARNING
WARNING
beforehand, set the range selector at the highest position.
WARNING
