SPARE PARTS LIST
No Part Name
63 stator
64 ball bearing 608RS-SYBS
65 motor casing
66 brush
67 brush carrier
68 brush box
69 at washer 5
70 spring washer 5
71 soket head cap screw M5×60
72 tail cover
73 pan head tapping screw ST4.2×16
74 oil ller cap
75 o ring 37.5×1.8
76 crank shaft
77 absorber boot
pressing plate
78
79 support ring
80 spring Φ1.8×Φ16×42
81 washer
bolt M10×61
82
at washer 4
83
84
spring washer 4
85 pan head screw M4×14
86
pan head tapping screw ST4.2×16
87
right handle
self-locking nut M6
88
89 switch
90
capacitance 0.33 F
91 speed controller
92 pan head tapping screw ST4.2×16
93 pressing block
No Part Name
94 carbon- lm resistor
95 LED
96 left handle
97 at washer 6
98 soket head cap screw M6×50
99
pan head tapping screw ST4.2×16
100 cable pressing plate
101 cable sheath
102 supply cord H07RN-F2X1.0-2.3
103 o ring 11×2
104 rotating shaft
105 switch holder
106 mode selector switch (drill stop)
107 spring 4.5×0.6×20
release button
108
109 pan head screw M5×14
110 spring washer 5
111
at washer 5
112
square head screw M8×50
113 depth gauge
hoop
114
115 grip base
116 saddle
assistant handle
117
118 pan head screw M4×14
119 at washer 4
spring washer 4
120
cylindrical pin 4×4.2
121
clutch
122
201 bevel pinion
202 at key 3×10
No Part Name
203 bearing 6002Z-BNCHC
204 locating ring 4.7
205 gear holddown
206 second gear
207 steel ball 5.5
208 spring
209 gear holder
210 nut
211 bearing 627Z-SYBS
