B. Remote control
1. Depress the power button in front of the amplifier to set the system to Standby mode.
2. Depress the ST-BY button on the remote control to activate the system
3. Depress the INPUT SEL button to select the source input between PC or AUX
4. Start the playback device and adjust the volume to your listening pleasure.
5. On the remote control, various volume levels can be adjusted.
6. Depress the Volume +/- buttons to adjust the master levels.
7. Depress the BALANCE R/L buttons to balance the right and left volume levels.
8. Depress the TREBLE +/- buttons to adjust the high frequency levels.
9. Depress the BASS +/- buttons to adjust the low and mid range frequencies.
10. Depress the 3D button, to activate or deactivate the surround effect.
11. Depress the MUTE button to turn off the audio output temporary.
Depress again to turn on or simply depress any volume buttons.
Ideal listening position and placement
A -amplifier
FL -front left
FR -front right
RC -remote control
EN
5
A
FL FR
RC
Technical Information
Amplifier
Output power, RMS
Power distribution, Watt
Harmonic distortion
Frequency response
Signal/Noise ratio, dB
Separation, dB
Input sensitivity, mV
Nominal impedance, ohm
Speakers
Tweeter driver type
Tweeter rated power
Bass driver type
Bass rated power
Frequency range
Interfaces
Output
Input
Auxilliary
DC power
AC power
Fuse
Others
Dimensions
Product dimensions mm
Product Net weight kg
Frequently Asked Questions (FAQ)
Problem
Solutions
Check if the system is powered on
Power LED won t light up
Check the power plug well connected
Check if the audio source is working well
No Sound
Check if the audio and speaker cables well connected
Check if the volume at right level
Check if the satellite cable well connected and ensure source
One or more satellite no sound
connection is correctly inserted
Static sound heard when volume Turn off the playback source first then turn the speaker
knob is turned
volume knob several times Playback again and monitor The
static noise is due to dust so simply turning the volume will
remove it easily
What are the products supported ?
Any playback devices such as PC notebook CD DVD player
Media Players with 3 5mm stereo plug
Sound is distorted
Check if the source file is not corrupted play a different song
and test
Remote control not working
Check if the battery in the remote control
Where to place this speaker
It is magnetically shielded so can be placed near LCD TV
Monitor without any distortion
If the problem still exists, please contact the distributor or ask for professional service
60 Watt
30 Watt x 2
< 0.3% 1W 1kHz
45Hz - 20kHz
> 65dB
> 40dB
340mV
8 ohm
1"
5.25"
40 Watt x 2
20Hz - 20kHz
Terminals
2RCA
2RCA
220V - 240V, 50Hz
T800mAL250V
Includes remote control
Amplifier: 90 x 315 x 252
Speakers: 185 x 215 x 290
11,95
