システム セットアップ:
miniStack v2.5 外付けドライブ エンクロージャおよび拡張
ハブは、簡単にコンピュータに接続できます。
この新しい外付けストレージおよび拡張デバイスを最大限
に活用するためのヒントを以下に挙げます。
Mac mini または Apple AirPort Extreme Base
Station をお持ちの場合、miniStack エンクロ
ージャはこれらの下にぴったり収まるので、
デスク上のスペースを節約いただけます。
miniStack
る物を置かないでください。
miniStack
の場所に保管し、直射日光は避けてください。
miniStack
接続する前に損傷がないか常に確認してください。
ハブ接続
USB 2.0 または FireWire (1394a) のいずれかのハブ機能を
利用するには、同梱されているケーブルでコンピュータ
と miniStack v2.5 を接続します。miniStack 側の 3 つの
FireWire ポートのうち 1 つと、Mac mini 側の FireWire コネ
クタを使って、コンピュータとエンクロージャを FireWire
ケーブルで接続します。マシン間の USB 2.0 接続も同様に行
いますが、この場合 miniStack の USB 2.0 アップリンク ポ
ートを使ってコンピュータに接続します。
ハードディスク モード:
Newer Technology miniStack v2.5 エンクロージャでは、
最適パフォーマ
お使いのコンピュータで最高速の接続が検出され、
ンスを得るに
自動的にその接続を使ってマウントされます。
は、miniStack を
FireWire と USB の両
方を使ってコンピュータに接
ファン設定:
続することをお勧めします。
miniStack v2.5 には、ドライブ エンクロージャ内の熱温度
USB 2.0 はスループット理論値
を監視する冷却ファンがあり、必要なときにのみ稼動しま
が FireWire より高いとされて
いますが、実際のテストでは
す。ファン速度を変更するための設定調節は必要ありませ
FireWire のデータ転送速度が
ん。
USB 2.0 より高いことが確認さ
れています。
FireWire と USB の両方を接続
することにより、FireWire の
データ転送速度と USB ハブの
多用途性が可能になります。
6
の後側には通気の妨げにな
はコンピュータと同様に、乾燥した低温
に使用する周辺機器用のケーブルは、
Using your Newer Technology miniStack v.2.5
Remove the Newer Technology miniStack v2.5 from its packaging
and examine the back of the enclosure. You will see the following
ports:
1.
Smart Power Switch
long as the power switch is in the ON position, the mini-
Stack will power on and off with your computer - no need
to shut the enclosure off when done!
Power Receptacle
2.
Remember -
Your miniStack also
3.
USB 2.0 Ports
functions as both a
4.
USB Uplink Port
FireWire and a USB 2.0 Hub.
H b
here.
You can hook up your favorite
peripherals using the extra ports
5.
FireWire (1394a) Ports
like you would with any other
computer using the included cable and have two extra
FireWire or USB hub.
ports to add peripherals with!
6.
Kensington Security Slot
desk using a Kensington MicroSaver Security Cable (not
included).
7.
Smart Fan Exhaust Port
miniStack through this port.
- Used to turn the miniStack on. As
- Used to power the miniStack.
- Add USB devices to your miniStack here.
- Connect your computer to the miniStack
- Connect one FireWire port to your
- Secure your miniStack to your
- Warm air is vented from your
3
