MB QUART DHG 304 D Handbuch Seite 8

R E F E R E N C E / D I S C U S
H G - S U B B O X E S
RHG 304 D
DHG 304 D
RHG 304 S
Dual-Mode (2 x 4 Ohm Load)
12 V DC
(
DHG 304 S
12 V DC ( )
)
Serial-Mode (8 Ohm Load)
Speaker Speaker
Terminal 2 Terminal 1
+
Parallel-Mode (2 Ohm Load)
Speaker Speaker
Terminal 2 Terminal 1
+
12 V DC ( )
+
+
12 V DC
( )
