- Seite 1 rfi filter installation instruction...
- Seite 2 rfi filters Before starting the RFI filter installation, read the safety section in the drive installation manual. 9000.emf Table 1. RFI filters for drive frame sizes 4-7 Nominal Frame Rated voltage, 3~, current at Dimensions Weight size Filter type code 50-60Hz [V 50°C [A] W x H x D [mm]...
-
Seite 3: Delivery Contents
delivery contents The delivery includes the RFI filter, this installation manual and an installation kit. Table 2. Installation kit contents Parts/filter size Part Size/type 49x75.5mm, hole Ø28mm IP54 cover 70x108.5mm, hole Ø47mm 90x145mm, hole Ø47mm 54x80mm Gasket for IP54 cover 75x112mm 95x150mm Ø28mm... -
Seite 4: Dimensional Drawings
dimensional drawings Figure 3. RFI filter assembly, size 4, dimensional drawing Figure 4. RFI filter assembly, size 5, dimensional drawing... - Seite 5 Figure 5. RFI filter assembly, size 6, dimensional drawing Figure 6. RFI filter assembly, size 7, dimensional drawing...
- Seite 6 filter mounting The RFI filter can be installed in two ways. Back installation 1. Install the RFI filter on the wall with four screws. 2. Install the drive on top of the filter with the four mounting screws supplied in the installation kit (six screws in filter size 5).
- Seite 7 Side installation 1. Install the RFI filter on the left side of the drive, so that the filter cables do not cross the motor cables. Use three mounting screws. In IP21 drives, leave a minimum of 20mm between the filter and the drive.
- Seite 8 min. 20mm Figure 8. RFI filter side installation...
- Seite 9 filter cabling Table 3. Filter input cable sizes and screw tightening torques Cable size [mm Tightening torque [Nm] Filter size Install the IP54 gasket. Installieren Sie die 54-Dichtung. Installez le joint d'étanchéité IP54. Instale la junta de protección IP54. Installare la guarnizione IP54. Plaats de IP54-pakking.
- Seite 10 Install the IP54 cover with the two screws supplied in the installation kit. Tighten the screws to torque 1.25Nm (in filter sizes 4-5) or NOTE! 1.5Nm (sizes 6-7). Install a cable clamp to prevent pulling of the mains cable. Installieren Sie die IP54-Abdeckung mit den zwei im Installationssatz mitgelieferten Schrauben.
- Seite 11 drive cabling NOTE! For more detailed instructions, see the drive installation manual. Release the four screws and remove the front cover. Lösen Sie die vier Schrauben, und entfernen Sie die Frontabdeckung. Desserrez les quatre vis et retirez le cache avant. Afloje los cuatro tornillos y retire la tapa delantera.
- Seite 12 1. Install the cables from the filter to the drive input and earthing terminals. 2. Remove the marked EMC jumper L1 L2 L3 from the drive (EMC screw in MR7). 3. In MR4, attach the additional earthing wire to the frame. 1.
- Seite 13 Re-attach the connection cover and front cover (see steps 1 and 2). Mark “External RFI filter” on the Drive Modified-sticker and place it on the side of the drive. The sticker is included in the drive accessories bag (see the drive installation manual). Setzen Sie Anschluss- und Frontabdeckung wieder ein (siehe Schritte 1 und 2).
- Seite 14 Find your nearest Vacon office on the Internet at: www.vacon.com Manual authoring: documentation@vacon.com Document ID: Vacon Plc. Runsorintie 7 65380 Vaasa Finland Subject to change without prior notice © 2013 Vacon Plc. Rev. V001...
