Air Circuit - Astralpool CDP LINE V2 Technisches Handbuch

ASTRALPOOL CDP LINE V2

AIR CIRCUIT

© ASTRALPOOL 2015 ALL RIGHTS RESERVED. PROPRIETARY DOCUMENT
N⁰ DESCRIPTION
Thermal insulation
Temperature sensor
Air plate
Lower air plate
Post heating coil
Post heating coil
Air heating elements
Air heating elements
Fan fixing plate
Fan
Fan
Condenser coil
Condenser coil
Evaporator coil
Evaporator coil
.
ANNEX
MODEL CODE
All 65891R021
All 65891R022
All 65891R023
All 65891R024
Opt. 2 & 3 65895R001
Opt. 4 & 5 65897R001
Opt. 2 & 3 65899R001
Opt. 4 & 5 65901R001
2 - 3 - 4 65891R025
2 - 3 - 4 65891R026
5 65894R001
2 & 3 65891R027
4 & 5 65893R001
2 & 3 65891R028
4 & 5 65893R002
