1. Features

This board enables input of SDI signals when inserted into the slot of an NEC monitor or
projector. It is also equipped with a loop-through output terminal for monitoring.

2. Checking the Included Parts

- 3G/HD/SD-SDI board (this board)
- Operating Instructions (these instructions)
PLEASE
- When discarding this board, contact your store of purchase or local government.

3. Names of Parts

Board front panel
Monitor output terminal (BNC)
Board rear panel
NOTE
• Do not touch the connector on the rear panel. If touched, static electricity could cause
malfunction.
SDI input terminal (BNC)
Grip
Connector
