Redundant MADI Function
• Simple schematic illustrating the MADI changeover function in Dual Link redundancy mode.
BR C/O
Tx
Main
Blackrock
Rx
Fibre C/O
Blackrock and Alpha-Link LIVE-R will automatically switch to their backup fibre ports in the event of a main fibre
failure.
Tx
Main Fibre Port
Rx
Tx
Backup Fibre Port
Rx
Rx
Tx
Alpha-Link LIVE-R
Rx
Tx
