Inhaltszusammenfassung für Klipsch R-20B
- Seite 2 CONTENTS CONTENU • CONTENIDO • INHALT • CONTENUTO • CONTEÚDO • 目录 Soundbar Subwoofer MAKE SURE TEMPLATE IS LEVEL BEFORE DRILLING PILOT HOLES! Pilot Pilot Hole Hole WALL MOUNT TEMPLATE Wall-Mount Template Remote Soundbar Subwoofer Wall-Mount Template Remote Barre de son Caisson de graves Gabarit de montage mural Télécommande...
- Seite 3 MAKE SURE TEMPLATE IS LEVEL BEFORE DRILLING PILOT HOLES! Pilot Hole WALL MOUNT TEMPLATE AC Adapter / Power Cord Rubber Feet Digital Optical Cable SURE TEMPLATE IS LEVEL BEFORE DRILLING PILOT HOLES! AC Adapter / Power Cord Rubber Feet Digital Optical Cable Pilot Hole WALL MOUNT TEMPLATE...
- Seite 4 BUTTONS Touches • Botones • Tasten • Pulsanti • Botões • 按钮 On / Off Volume Up Volume Down Volume Volume Status Status Mute Source Mute Down Light Light Source Bluetooth ® 3D Surround On /Off Mute 3D Surround Source Volume Up Volume Down Sous tensio / Hors tension...
-
Seite 5: Digital Audio Out
DIGITAL OPTICAL CONNECTION (PREFERRED - IF TV HAS NO OPTICAL OUT SEE NEXT PAGE) CONNEXION OPTIQUE NUMÉRIQUE • CONEXIÓN ÓPTICA DIGITAL • OPTISCHE DIGITALVERBINDUNG • CONNESSIONE OTTICA DIGITALE • CONEXÃO ÓTICA DIGITAL • 数字光纤连接 Soundbar DC IN Optical Factory Use Only Power Optical Digital Audio Out... - Seite 6 3.5mm TO DUAL RCA ANALOG CONNECTION (IF TV HAS NO HEADPHONE OUT SEE NEXT PAGE) CONNEXION ANALOGIQUE 3,5 MM VERS DOUBLE FICHE RCA • CONEXIÓN ANALÓGICA RCA DE 3.5 MM A DOS RCA • 3,5 MM ZU DOPPEL-CINCH-ANALOGKABEL • CONNESSIONE ANALOGICA CON JACK DA 3,5 MM A DOPPIO JACK RCA CONEXÃO ANALÓGICA DE 3,5 MM • PARA RCA DUPLO •...
-
Seite 7: Audio Out
DUAL RCA TO DUAL RCA ANALOG CONNECTION CONNEXION ANALOGIQUE DOUBLE FICHE RCA VERS DOUBLE FICHE RCA • CONEXIÓN ANALÓGICA DE DOS RCA A DOS RCA • ANALOGVERBINDUNG (DOPPEL-CINCH ZU DOPPEL-CINCH) CONNESSIONE ANALOGICA DA DOPPIO JACK RCA A DOPPIO JACK RCA • CONEXÃO ANALÓGICA DE RCA DUPLO PARA RCA DUPLO • 双 RCA 转双 RCA 模拟连接 Soundbar DC IN Optical... -
Seite 8: Subwoofer Wireless Connection
SUBWOOFER WIRELESS CONNECTION Connexion sans fil du caisson de graves • Conexión inalámbrica del subwoofer • Drahtlose Verbindung zum Subwoofer • Connessione wireless con il subwoofer • Conexão sem fio do subwoofer • 低音炮无线连接 Soundbar - Power On 50 ft. (15m) Soundbar - Power On 50 ft. -
Seite 9: Bluetooth ® Wireless Technology
R-20B CONECTAR Not Paired Connected Settings Bluetooth Settings Bluetooth 连接 Phone Bluetooth Bluetooth Klipsch R-20B Solid Blue Devices Devices R-20B R-20B Not Paired Connected Phone Klipsch R-20B Solid Blue Recommended 30 feet max distance between music source and soundbar for optimum performance. -
Seite 10: Soundbar Placement
SOUNDBAR PLACEMENT POSITIONNEMENT DE LA BARRE DE SON • UBICACIÓN DE LA BARRA DE SONIDO • SOUNDBAR-PLATZIERUNG • COLLOCAZIONE DEL SOUNDBAR • POSIÇÃO DA BARRA SONORA • 条形音箱布置 .25” (6.35mm) .25” (6.35mm) -
Seite 11: Subwoofer Placement
SUBWOOFER PLACEMENT POSITIONNEMENT DU CAISSON DE GRAVES • UBICACIÓN DEL SUBWOOFER • SUBWOOFER-PLATZIERUNG • COLLOCAZIONE DEL SUBWOOFER • POSIÇÃO DO SUBWOOFER • 低音炮布置... -
Seite 12: Tv Remote Programming
TV REMOTE PROGRAMMING TV REMOTE PROGRAMMING • PROGRAMMATION À DISTANCE DU TÉLÉVISEUR • PROGRAMACIÓN DEL CONTROL REMOTO DEL TELEVISOR • PROGRAMMIEREN DER TV-FERNBEDIENUNG PROGRAMMAZIONE CON IL TELECOMANDO TV • PROGRAMAÇÃO DO CONTROLE REMOTO DA TV • 电视机遥控器编程 Press and Hold Solid Green 12 in. - Seite 13 Press and Hold Flashes Yellow Solid Yellow Appuyer sans relâcher Clignotement Jaune Jaune continu Oprima y mantenga oprimido Destella Amarillo Amarillo continuo Gedrückt halten Blinkt Gelb Dauerhaft Gelb Tenere premuto Giallo lampeggiante Giallo a luce fissa Pressionar e manter pressionado Amarela intermitente Amarela constante 按住...
-
Seite 14: Remote Control Codes
REMOTE CONTROL CODES 41609 HEX CODES - SET 1 HEX CODES - SET 2 ONE FOR ALL 1609 0531 VOLUME UP 0x 856A 9F60 VOLUME UP 0x 02A1 DF3B DIRECTV 31609 30531 VOLUME DOWN 0x 856A 9E61 VOLUME DOWN 0x 02A1 DF3F XFINITY 30531 MUTE... -
Seite 15: Turn Off Tv Speakers
TURN OFF TV SPEAKERS MISE HORS TENSION DES HAUT-PARLEURS DU TÉLÉVISEUR • APAGADO DE LOS ALTAVOCES DEL TELEVISOR • TV-LAUTSPRECHER DEAKTIVIEREN • SPEGNIMENTO DEGLI ALTOPARLANTI DEL TELEVISORE DESLIGUE OS ALTO-FALANTES DA TV • 关闭电视机扬声器 TV Audio Settings Menu TV Speakers Volume (Recommended) CARE AND CLEANING... - Seite 16 3502 WOODVIEW TRACE, INDIANAPOLIS, IN, USA KLIPSCH.COM ©2014, Klipsch Group, Inc. Klipsch Group, Inc. is a wholly-owned subsidiary of Voxx International Corporation. Klipsch and Keepers of the Sound are trademarks of Klipsch Group, Inc., registered in the United States and other countries. The Bluetooth ®...
