OPERATION MANUAL AND INSTRUCTIONS
PERSONAL PROTECTIVE EQUIPMENT TO WEAR WHILE OPERATING PNEUMATIC TOOL
Failure to observe the following warnings may result in physical injury and/or disease.
ALWAYS WEAR HEARING PROTECTION WHILE OPERATING PNEUMATIC TOOL
ALWAYS WEAR EYE PROTECTION WHILE OPERATING PNEUMATIC TOOL OR
PERFORMING MAINTENANCE JOBS
ALWAYS WEAR PROTECTIVE GLOVES AGAINST PHYSICAL AGENTS WHILE
OPERATING PNEUMATIC TOOL
ALWAYS WEAR SAFETY SHOES
Additional personal protective equipment to wear according to the values found in the environmental
hygiene/risk analysis survey if the values exceed the limits under current regulations.
WEAR ANTI-VIBRATION GLOVES WHILE OPERATING PNEUMATIC TOOL
FOLLOWING A SPECIALLY CONDUCTED SURVEY OF LEVEL OF DAILY
EXPOSURE OF HAND-ARM SYSTEM TO VIBRATION
WEAR PROTECTIVE MASK AGAINST PHYSICAL AGENTS ACCORDING TO THE
VALUES FOUND IN THE ENVIRONMENTAL/INDUSTRIAL HYGIENE SURVEY
WEAR PROTECTIVE HELMET
TECHNICAL DATA
TRACTIVE FORCE
STROKE LENGTH
AIR INLET
MINIMUM HOSE SIZE ø
MAXIMUM PRESSURE
MAXIMUM AIR CONSUMPTION
WEIGHT
LENGTH
HEIGHT
MAXIMUM RIVET CAPACITY
NOISE (ISO 15744)
SOUND POWER LEVEL
SOUND PRESSURE LEVEL
VIBRATIONS (ISO 28927)
VIBRATION LEVEL
UNCERTAINTY
10
8900 N
15 mm
1/4" GAS
10 mm
6,2 bar
2,6 l/cycle
1,5 Kg
290 mm
245 mm
Ø 4.8 mm
L = 83,8 dB
wA
L = 72,8 dB
pA
0,48 m/s
2
K=0,54 m/s
2
EN
