Quick Start Guide (En) - Zotac ZBOX series Schnellanleitung

Quick Start Guide
Setting up your ZOTAC ZBOX
1. Select your ZOTAC ZBOX position
i. Place ZOTAC ZBOX sideways
ii. Install ZOTAC ZBOX on the stand
iii. Mount ZOTAC ZBOX to a monitor
2. Connect antennas for WiFi &
Bluetooth
3. Connect to a home network
4. Connect USB devices
5. Connect a display
6. Connect power cable
7. Turn on the system
8. Install operating system
Status LED (optional)
System is on
System is off
System is in standby mode LED flashes slowly
Front panel
1. Headphone/Audio Out
jack
2. Microphone jack
3. Memory card reader
(MMC/SD/SDHC/
SDXC)
4. USB 3.0 port
5. WiFi LED (optional)
6. Hard drive LED
7. IR Receiver
8. Power button
Rear panel
1. WiFi antenna connector
2. Optical S/PDIF output
3. LAN (RJ45) ports
4. USB ports
5. DVI port
6. HDMI port
7. Bluetooth antenna
connector
8. Power input (DC19V)
1
i
2
3
4
LED is on
LED is off
1 2
1 2 3
5
6
2
3 4 5
4 5
ii
iii
7
6 7 8
6 7 8
3
