The headset's audio indicators:
Headset action
Volume Limit
Low Battery Tone
Out of Range
Incoming Call from Mobile
Incoming Call from desk phone
Pairing Confi rmation
– with base
– with mobile
Establish Audio Link
Initiate Voice Dial
Voice Tag not Recognised
End Call/Audio Link Closed
Power ON/OFF
The headset's visual indicators:
Headset mode
Power Off
Charging in Process
Charging Complete
Pairing Mode
Pairing Successful
Audio Link (on a call)
Headset ON
Headset ON and in range of base
Opened boom arm (turn ON)
Closed boom arm (turn OFF)
Test link established
The base's visual indicators:
Base's on-line indicator
On-line with a call
Base's pairing indicator
Pairing Mode
Pairing Successful
Base reset Successful
GN6110_contents_EU_13-02-2004.indd 15
Audio indication
Repeated single high tone when min. or max.
limits achieved (when button is pressed)
Two rapid high tones repeated every 20 seconds
No audio indications; gradual deterioration of
audio quality
Ring tone A
Ring tone B (only when using hook switch)
2 single tones
1 single tone
Series of tones, low to high
Single low tone
Dual high-low tone
Series of tones, high to low
No audible tone
Headset indicator
OFF (no charger)
ON (charger plugged in, or headset placed in
base)
OFF (charger plugged in, or headset placed in
base)
ON (no charger) with headset boom arm opened
Series of 10 rapid fl ashes
Rapidly fl ashes
Continuous single fl ash (slow)
Continuous double fl ash (slow)
Lights for two seconds
Lights for two seconds
Rapidly fl ashes
On-line indicator
Flashes
Pairing indiator
ON
Series of 10 rapid fl ashes
Lights for two seconds
