5.2.4 Installation in multiple combinations

The device can be used with frames of other manufacturers or be integrated in a
multiple frame. For installation in multiple combinations, install the mounting plate
of the device flushing with the already installed mounting plates/bearer rings and
align it to these. The device will fit into the frames of the following manufacturers:
Manufacturer
Berker
ELSO
GIRA
merten
JUNG

6 Operating modes and configuration

The setting wheel E provides the operating functions of the device. Depending on
the configuration, the settings are transmitted to the Alpha IP Base station or to
the Alpha IP app.

6.1 Configuration menu

The configuration menu is opened by pressing and holding the setting wheel (E).
The following symbols/menus are available by rotating the setting wheel; shortly
pressing the wheel will select them.
Frames
S.1, B.1, B.3, B.7 Glass
Joy
System 55, Standard 55, E2, E22, Event, Esprit
1-M, Atelier-M, M-Smart, M-Arc, M-Star, M-Plan
A 500, AS 500, A plus, A creation
Operating modes and configuration
