GB

DESCRIPTION OF PARTS

Fig.1 - transmitter box
1 Box
2 Fixing brackets
3 Seal
4 Cover
Fig. 4 - Transmitter
1 Pt1 button
2 Setting dip-switches
3 Indicator LED
4 Terminal board for sensitive edge input
Fig. 7 - Receiver
1 Setting dip-switches
2 Indicator LED
3 Pr1 memorisation button
4 TEST input terminal board
5 Power supply and SENSITIVE EDGE signal output terminal
board
6 COSTA 2 (SENSITIVE EDGE 2) setting jumper
7 COSTA 1 (SENSITIVE EDGE 1) setting jumper
8 12/24 V power supply selection jumper

INSTALLING TRANSMITTER

1) Mount the transmitter with the aerial pointing downwards and
near the sensitive edge (Fig. 3).
2) Connect the sensitive edge to the transmitter terminal board (4
in Fig. 4). The edge must be of the 8.2 kOhm balanced type.
Run the cables as closely as possible to the terminal board
(Fig. 2).
3) Insert the batteries into the transmitter taking great care with
the polarity and check that the LED (3 in Fig. 4) lights up
momentarily.
