Wear adequate clothing,
gloves and goggles before carrying
out any maintenance.
• The frequency and types of maintenance
are summarised in the "Maintenance
Table". The table will help you maintain
your machine's safety and performance.
It summarises the main interventions to
be made and the frequency applicable
to each of them. Carry out the relevant
intervention according to the first deadline.
• The use of non-genuine spare parts and
accessories could adversely affect machine
operation and safety. The manufacturer
shall decline all liability in the event of
injuries or damages caused by such parts.
• Genuine spare parts are supplied
by authorized assistance
workshops and dealers.
IMPORTANT All the maintenance and
adjustment operations not described
herein must be carried out by your dealer
or Authorised Service Centre.
7.2 REFUELLING
To refuel:
1. Unscrew the tank closure cap
and remove it (fig. 10.F).
2. Insert the funnel (fig. 10.G).
3. Refuel and remove the funnel (fig. 10.G).
4. Close the fuel cap securely after refuelling
and clean away any spills (fig. 10.F).
NOTE Do not fill the fuel tank right to the top.
NOTE Only use the fuel indicated in the data
table. Do not use other types of fuel. It is possible
to use ecological fuels, i.e. alkylate petrol. The
composition of this petrol is less harmful to
people and the environment. No negative effects
linked to use of the same have been reported.
However, there are types of alkylate-based
petrol available on the market for which it is not
possible to give precise indications regarding
their use. For further information it is advisable
to consult the instructions and data provided
by the producer of the alkylate-based petrol.
NOTE Fuel is perishable and should not remain
in the tank for more than 30 days. Before storing
for a long period, fill the tank with a sufficient
amount of fuel to reach final destination (chap. 8).
7.3 CHECK/TOP-UP ENGINE OIL
Always check the oil level before use.
NOTE The machine is delivered
to the client without engine oil.
7.3.1 Check/top-up
Procedure:
• Position the machine on a level
surface for the check.
• Wipe around the dipstick. Unscrew it and
pull it out. Clean the dipstick (fig.10.H).
• Push the dipstick down completely
without screwing it into place.
• Now pull the dipstick up again.
Read off the oil level.
• Top up using the oil extension hose (fig.3.E) if
the level is lower than the "MAX" mark (fig.12)
• For the correct replacement
procedure, see par. 7.3.2
Do not overfill as this could cause
the engine to overheat. If the oil level
exceeds the "MAX" mark, the oil must be
drained until the correct level is achieved.
NOTE For the type of oil to use,
see the "Technical Data Table".
7.3.2 Replacement
The oil may be very hot if removed
just after the engine has been switched
off. Consequently allow the engine to
cool down for a few minutes before
proceeding to drain off the oil.
Replace the engine oil based on the frequency
indicated in the "Maintenance Table". Change
the oil more frequently if the engine has
to operate in demanding conditions.
Proceed as follows:
1. Place the machine on a flat surface.
2. Place a suitable container
under the drain plug.
3. Remove the top-up cap (fig. 10.H)
4. Remove the drain cap (fig. 10.I)
5. Collect the oil in a suitable vessel.
6. Screw the oil drain plug back in.
7. Clean up any spills.
8. Fill with fresh oil. For the quantity of oil to
use, see the "Technical data table".
9. After filling up the oil, start the engine
and leave it to idle for 30 seconds.
10. Check there are no oil leaks.
11. Stop the engine. Wait 30 seconds and
check the oil level again. If necessary,
also see "check/top-up" (par. 7.3.1).
IMPORTANT Hand the spent
oil over to a disposal facility in
accordance with local provisions.
