5 5
68x47 mm (ØxP)
DIN 49073
4
6 6
VORT HRW 20 MONO D
1
2
3
Wires color code
BK=black
BU=blue
BN=brown
GNYE=yellow/green
RD=red
WH=white
YE=yellow
VT=violet
6
Ferrite
3
1
Main supply
220-240 V
50/60Hz
HRW RC D + PS36WDIN
(Cod. 21.145 + Cod. 21.189)
1
2
RD
VT
BU
16-24 AWG
2
0.35-1.5mm
- C +
TO REMOTE CONTROL (HRW)
24
