Bluetooth
Receiver
Art.no 38-3764 Model Rx2
Please read the entire instruction manual before
using the product and save it for future reference.
We reserve the right for any errors in text or ima-
ges and any necessary changes made to techni-
cal data. If you have any questions regarding
technical problems please contact Customer
Services.
Product description
Bluetooth Receiver. Connect the receiver to your
stereo system using the RCA or 3.5 mm plug.
You can then stream music from your mobile
phone, laptop or other Bluetooth-compatible
device which supports A2DP. The receiver is
charged via the included USB lead. Operating
time: approx. 8 hours. Range: approx. 10 m.
Contents
• Bluetooth receiver
• USB charger lead
• RCA cable
• 3.5 mm connecting cable
• Instruction manual
Buttons and functions
3.5 mm
LED indicator stereo socket
On/off
Mini-
USB port
GREAT BRITAIN • customer service tel: 08545 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Charging
1. Connect the Mini-USB connector on
the charger lead to the device.
2. Connect the other end to a computer.
The LED will be lit during charging.
3. When the charging is complete the
LED will turn off.
4. Remove the charger lead.
Pairing (Synchronising)
1. Pairing is the process of creating a wireless
connection between the Bluetooth source
device and the Bluetooth receiver.
2. Before pairing make sure that both devices
are fully charged.
3. Make sure that no other Bluetooth devices
are also activated in close proximity.
4. Turn on the Bluetooth receiver by depressing
the on/off button for 7 seconds. The LED will
flash alternately between blue and red. This
indicates that the device is in pairing mode.
5. Search for "RX2" on your mobile phone or
other transmitter. Use the "0000" password
to begin pairing.
6. Both devices will begin pairing and the
receiver will slowly flash when the process
is complete.
7. The LED will then transition into a solid blue
once the devices are paired.
8. To shut off the Bluetooth receiver, depress
the on/off button for 5 seconds.
Playing music
1. Connect the Bluetooth receiver to
your sound system using one of
the included cables.
2. Make sure that the transmitter (mobile
phone, etc) is on and paired with the
Bluetooth receiver and is within a range
of 10 metres.
3. When the receiver's LED slowly flashes blue
it means that the connection is satisfactory.
4. Play a song on the transmitter and it will
stream to your Bluetooth receiver.
• If the connection is not working, restart
your receiver. Repeat the processes
described above.
• The two most common reasons why
a connection is broken are that the source
transmitter is outside a 10 metre range,
or that the battery is weak.
Care and maintenance
Wipe the product using a dry cloth as and
when required. Never use abrasive cleaning
agents or solvents.
Disposal
Follow local ordinances when disposing of this
product. If you are unsure of how to dispose of
this product, please contact your local authority.
Specifications
Size 49 × 21 × 12 mm
Bluetooth version V.2.1, class II, 10 metres
Bluetooth stereo profile A2DP
Frequency 2.4 GHz
Current draw Energy saving
stand-by function
Certifications CE and FCC
Up to 8 hours
Operating time
Declaration
of Conformity
Hereby, Clas Ohlson AB,
declares that following product(s):
38-3764 / RX2
Bluetooth Audio Receiver
is in compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC.
Article 3.1a (Safety): EN 60950-1
Article 3.1b (EMC): EN 301489-1
EN 301489-17
Article 3.2 (Radio): EN 300328
Insjön, Sweden, May 2010
Klas Balkow
President
Clas Ohlson, 793 85 Insjön, Sweden
