EN Warning! Make sure the surface is level. The parts that need to be glued must not contain any
dust or grease, and must be dry (remove all seal-reducing substances)
First choose the location at which you wish to instal your LoooX Colour BoX.
Position the assembly kit sticker and place it level against the wall. (Take note! Ensure that the
surface does not contain any dust or grease, and is dry. Remove all seal-reducing substances).
Attach the assembly kit sticker in the desired position. Press firmly on the sticker (preferably
roll on).
Use the openings in the assembly-kit sticker to drill one or two holes in the wall, approximately
5 cm deep with a Ø10 mm drill bit. Remove any drilling residues from the drilled holes using a
vacuum cleaner,
Fill the drilled holes with approximately 20% assembly putty (Note: Do not place too much
putty, so that it does not emerge from the front side).
Attention! Also remove all dust and grease from the back of the LoooX Colour BoX and ensure
it is dry. Remove all seal-reducing substances.
Screw the supplied fastening pin(s) on to the threaded socket(s) on the back of your LoooX
Colour BoX.
Remove the protective foil from the assembly-kit sticker. Slide the LoooX Colour BoX.with
fixating pin(s) into the drilled holes. Press firmly on the LoooX Colour BoX. Also apply pressure
on the inside of the BoX for good adhesion. Do not place any loads for at least 24 hours.
Seal your LoooX Colour BoX. all round so that it is tightly sealed to the wall.
Complaints of damage in relation to an assembled LoooX Colour Box will be rejected.
Maximum load 50 kg. Assembly is possible only on even surfaces.
