WEDRY Basic Line WD 652 Betriebsanleitung Seite 16

WD 652
2. 2. 2. 2. 2. Care and maintenance Care and maintenance Care and maintenance
Care and maintenance Care and maintenance
Surface filter Surface filter Surface filter Surface filter Surface filter
Exhaust air filter Exhaust air filter Exhaust air filter Exhaust air filter Exhaust air filter
16
CAUTION CAUTION: CAUTION
CAUTION CAUTION
Switch off the unit and pull out the mains cable before cleaning,
servicing or repairing.
• If the unit is not to be used for a prolonged period, drain off all the
water otherwise unpleasant odours may occur.
• Check mains cable, connection cables and hoses for damage
before each start-up.
• Unlock the tank catches on both sides by pulling up.
• Detach suction head with handle and place on rear.
• Release the clips, and remove the flat panel filter and its frame
<A>.
• Push the filter out of the frame <B>.
• Fit either a new or cleaned filter into the frame, hook the frame into
the loops, and snap the clips into place.
Important Important Important Important Important: Ensure that the connecting rod for the filter cleaning
mechanism is slotted into the tab <C>.
• Place the suction head on the tank and lock with the tank catches.
Important Important Important Important Important: Ensure that the suction head is correctly mounted,
i.e. the switch is at the front.
< A >
• Clean the exhaust air filter at regular intervals.
- The exhaust filter can be removed after unlocking the rear
shutter.
- Rinse off under running water.
- The filter must be replaced if very dirty (see accessories for
order no.).
< B >
English English
English English English
< C >
