The RXP receiver is a component of the new Personal Pass system devised and
carried out by V2 S.p.A.
The main features concerning the above mentioned system are the following:
• It enables the control of 318 up to 1000 users.
• An incorporated connector enables you to put in memory modul of the
series: MEM200, MEM200-1,MEM1000, MEM 1000-I.
• The 3-segments display make the programming extremely easy.
• The Rolling Code Mode prevents any attempt of CODE duplication.
• The via radio self-learning system enables an easy and quick way of
memorizing the wished codes.
• By using the relé modules MLR it is possible to extend the riceiver up to
four channels.

TECHNICAL SPECIFICATIONS

12 V dc/ac between terminals 12 and 13
Power supply:
24 V c.a./c.c between terminals 12 and 14
Relay contact: 1A 30 V c.c.
Working temperature: -20°C ÷ +60°C
Consumption: 27 mA a riposo, 160 mA con quattro relè attivi.
Sensibility: > 110 dBm per S/N = 17 dB with m=100%
Radiations on aerial: < 66 dBm
Size: 160x135x77 mm
Weight: 440 g
Protection: IP55
FUNCTION OF CANC, UP, DOWN
The RXP receiver shows a menus program structure, each of them
corresponding to one of the receiver functions. When the program structure is
on, press the button UP or DOWN in order to select the menus, by shifting
forwards or backwards. Press CANC to get to the functions to be modified, by
pressing UP or DOWN.
PROGRAMMING
DISPLAY DESCRIPTION
rl Menu relay selection
Fun Menu relay functions
tEL Menu self-learning
CLt Menu memory module total clearing
rLC Menu ROLLING CODE mode
End End programming
For a correct programming, read the following instructions carefully:
• Carry out the electrical connections to the terminals, then supply power to
the receiver.
• The display shows three dashes;
• Press CANC and keep it pressed for about 3 sec.: the display shows the
writing rL, then release the button.
• Select the wished menu by pressing UP to go onwards and DOWN to go
backwards. For a quick shifting, keep the button pressed.
• Press CANC to get into the functions to be modified.
• Change the settings by pressing UP or DOWN;
• To confirm and get out of the menu press CANC.
• Once the modifications have been carried out, select the menu End.
• Press CANC to get out of the programming.
The RXP receiver is ready to be used and newly programmed.
MENU RELE' SELECTION (rL)
It enables to select one of the four available relays: the transmitters which will
be memorized afterwards will be associated to the chosen relay.
FUNCTION
from 1 to 4 Relay
Mon / biS / tiM
from 0 to 999 TX
no / Yes
no / Yes
- - - - - - - - - - - - - -
FUNCTIONS MENU (Fun)
It enables the selection of one of the following functions:
Mon: it activates the corresponding relé through the time of transmission.
When the transmission stops, the relé is disconnected.
BiS: it activates the corresponding relé on the first transmission, on the
second transmission the relé is disconnected.
tiM: the tx transmission activates the corresponding relay, which goes
automatically off after a time to be set from 1 to 450 seconds.
If the selected function is tiM (time relay), it is necessary to set the time of
relay activation:
• Press the button CANC, the display shows: 001
• Select the wished time (between 1 and 450 seconds) by pressing UP or
DOWN.
• Press CANC to confirm.
The transmitters to be memorized afterwards are associated to the chosen
function.
BEFORE MAKING ANY OPERATION, CHECK IF THE MEMORY MODULE IS
CORRECTLY PLUGGED IN THE APPROPRIATE CONNECTOR.
SELFLEARNING MENU (tEL)
This menu enables the memorization of the wished remote controls.
According to the memory module you have employed, it will be possible to
insert from 318 to 1000 different codes. During the learning processthe
display shows the number of the MEMORY ZONE: if the number on the
display is still the zone is free, whereas it flashes if the zone is busy.
It is possible to insert the wished remote controls sequentially or in the wished
MEMORY ZONES: to carry out a quick shifting, it is necessary to keep UP or
DOWN pressed.
ERROR MESSAGES:
Er1 faulty memory modul or not correcly inserted
Er2 attempted insertion of a code already memorized
TOTAL CLEARING MEMORY MODULE (CLt)
this menu enables the complete clearing of the memory modul contents.
During this operation the display shows the writing CLr. Once the clearing is
ended, the display shows the writing Clt again.
ROLLING CODE MODE (rLC)
It is possible to enable or not the Rolling Code mode which prevents all
attempts of duplication of the Personal Pass code.
Si = ROLLING CODE mode activated
no = ROLLING CODE mode not activated
CLEARING OF A SINGLE CODE
It is possible to clear one or many memorized codes.
• To enter in programming press and hold CANC key until the display shows
rL, release the key (if no action is performed within 1minute, the RXP will
exit the program mode).
• Enter the programming and select the menu tEL.
• Press CANC, the display shows: 000
• Press UP or DOWN to select the memory zone containing the code to be
cleared (for a quick shifting keep the button pressed).
• The numbers on the display are still when the memory zone is free
otherwise the display flashes.
• To cancel this memory zone keep CANC pressed until the display stops
flashing: the memory zone is now available for a new programming.
ATTENTION: if the ROLLING CODE mode is activated, you have to use only
the transmitters of the Personal Pass system serialized with WINPPCL software
99/05/CE DIRECTIVE CONFORMITY
The receiver model RXP are in conformity with the provisions of the following
EC directive(s) (including all applicable amendments) and that the standards
referenced here below:
EN 60335-1, EN 301 489-1, EN 301 489-3, EN 300 220-3
Racconigi, 25/01/2002
V2 S.p.A. legal representative
A.Livio Costamagna
