EN

2.0 SPECIFICATIONS

REF FEATURES
2.1
Refrigerants
2.2
Safety
2.3 Power
2.4
Compressor
2.5
Cooling
2.6 Protection
2.7 Pressure
2.8
Temperature
2.9
Case
2.10
Size
2.11 Weight
REFRIGERANT LIQUID RATE
(Kg/Min) (Kg/Hr)
R22 2.30/138
R134-a 2.00/120
R410A 1.65/99
6

TECHNICAL SPECIFICATIONS

EPA Certified to ARI 740-98 for refrigerants, HFC,HCFC and CFC
Designed to meet UL1963, AS standards & EU equivalents
220/240 VAC/50Hz, 110-115 VAC/50Hz
3/4 HP oil less, BLDC motor drive
Fan direct
High pressure switch cutoff at 3850 Kpa
Compressor protected by brushless DC drive circuit
Max low side design pressure 2600Kpa
Max high side design pressure 3800Kpa
Operating range 10°C to 40°C
Injection moulded glass reinforced high impact
L 320mm X W 220mm X H 260mm
8.5 Kg
VAPOUR RATE
(Kg/Min) (Kg/Hr)
0.31/18.6
0.25/15
0.30/18
PUSH/PULL RESIDUAL
RATE TRAPPED
REFRIGERANT
(Kg/Min) (Kg/Hr)
(Kg)
7.10/426 <0.1
5.80/348 <0.1
7.00/420 <0.1
