Arrow SBS64 Montageanleitung Seite 18

Step 3: Top Wall Assembly
You will need for this page:
65004
66646
(QTY: 12)
(QTY: 18)
Corner Post
Assembly
INSIDE
INSIDE
65103
65923
(QTY: 10)
(QTY: 10)
Splice Post Assembly
Front
11122
11122
80137
Front
1
11120 11122
Right Door Left Door
Jamb Top Jamb Top
Corner Post
Assembly
11120
18
1
(3) Corner Post Assembly
(2) Splice Post Assembly
NOTE: TIGHTEN AT
THIS TIME
INSIDE
11120
80135
INSIDE
18FXa
