E N G L I S H
AS382L DUST COLLECTOR
(See figures in pages 21, 22, 23)
Read carefully the GENERAL SAFETY INS-
TRUCTIONS LEAFLET, which is included
in the machine documentation.
Before connecting the dust collector to
the mains ensure that the voltage is the
same as that on the dust collector.
The AS328L dust collector is designed for use with the
stationnary Virutex edge banders. This dust collector has
a powerful vacuum function and is equipped with two
motors. When used in conjunction with the edgebander,
it switches on automatically during the trimming cycle.
It may also be used as a normal vacuum, when used
with the "Optional Accessories" described in Section
5 of this manual.

2. TECHNICAL CHARACTERISTICS

Power max......................................................2300 W
Cooling...........................................................by-pass
Air delivery..................................................340 m
Water column vacuum...........................2200/mm H
Container capacity..............................................72 l
Remote control socket.............................2600 W max
Weight................................................................25 Kg
Weighted equivalent continuous acoustic
pressure level A (as per/EN 60335-2-69)........76,0 dB(A)
Acoustic power level A
(as per/EN 60335-2-69)........................................90,0 dB(A)
Uncertainty......................................................K=3 dB(A)
Wear ear protection!
Vibration total values
(as per /EN 60335-2-69).....................................a
Uncertainty..............................................K=1,5 m/s

3. STANDARD EQUIPMENT

Inside the box you will find the following components:
1. One AS382L dust collector - Ref 8200300
2. One flexible tube with connectors for edge bander
- Ref 8299204
3. One aspirator control cable for edge bander - Ref
8245458
4. Various documents
4. DESCRIPTIÓN
A - Polyester filter to set into the tank to pick up dust,
and to remove for liquid suction.
B - Filtering cartridge for very fine dust. To be removed
for liquid suction.
C - Suction inlet
D - Connection base to edge bander
E - Flexible tube with connectors for edge bander
F - Tank.
G - Outlet for electric tool.
H - Switch.
I - Float. Designed so that the liquid collected does not
get into the motors during collection.
J - Motor block.
K - Hooks for tightening of motor block to tank.
In order to keep in good efficiency the
machine it is useful to clean the filters
after each utilization.

5. OPTIONAL ACCESSORIES

8246233 Dust collector kit (Fig. A), comprising:
1. 8299157 2-m flexible hose
2. 8299158 Dual-purpose brush
3. 8299159 Liquids brush
4. 8202131 Flat nozzle
5. 8299092 Round PVC brush
6. 8202316 Tube
7. 8203317 Elbow tube
8. 8202134 Triangular nozzle
/h
3
8299173 Y-connector D.32 (Fig. A)
O
2
8299161 Paper filter bag for AS282K and AS382L
FITTING THE DUST BAG
Only use the dust bag with all the filters on their place.
The bag collects all the dust in conditions of hygiene.
If sucked in along with the dust, sharp or wet items
could damage the dust bag.
Change the bag when it has filled to two thirds with dust.
The bag cannot be reused. It must always be changed.
<2,5 m/s
2
h
2
5
