RADIO TRANSMITTER CODE SETTING
Your Micron has been factory pre-set. It is
suggested that you enter your own personal
code. Slide up the switch cover on the rear of
the unit and move any one (or more) of the 4
slides to the up 'ON' position. To receive the
signal on your TXR Receiver, repeat the process
duplicating the same code, your receiver will
automatically distinguish between Red, Yellow
and Green channels.
N.B. - (If you experience interference from
another angler within the receiver range, you can
simply alter one slide switch to select another
channel. This must be done to both Micron
Transmitter and Receiver).

LEAD CONNECTION

The Transmitter is marked G Y R to
match your colour coded leads. To
ensure the correct LED's illuminate on
your receiver, connect your leads to
the matching colour on your bite
alarms (if applicable).
