Manual: Evolution Series ES-180S RGY 3D
8. Connect a DMX controller to operate the laser.
9. Use the switches 1 - 9 to set the DMX address of the laser. Each switch represents a num-
ber. To define a number use the preceding number and multipy it by 2:
1
Switch
Number 1
This laser uses 13 DMX channels, so make sure that the next device uses an address that
doesn't overlap with this range.
Channel
1
2
3
Horizontal movement
4
Vertical movement
5
Zoom / size
6
Vertical cross mirroring
7
page 8 / 22
2 3 4
2 4 8
Value
0 - 64
65 - 127
128 - 191
192 - 255
0 - 167
168 - 255
0 - 255
0 - 167
168 - 255
0 - 167
168 - 255
0 - 10
11 - 104
105 - 154
155 - 204
205 - 255
0 - 150
151 - 255
5 6 7
16 32 64
Function
Laser off
Sound mode
Automatic mode
DMX mode
Pattern selection
Animations
Flashing patterns with increasing speed
manual movement
automatic movement with increasing speed
manual movement
automatic movement with increasing speed
no effect
manual size settings
automatic pattern enlargement with increasing
speed
automatic pattern contraction with incresaing
speed
automatic change of enlargement and contrac-
tion with increasing speed
manual mirroring
automatic mirroring with increasing speed
8 9 10
128 256 Mode Switch
