Troubleshooting

Problem
UPS not on, LCD not light
UPS always at battery mode
Buzzer continuous beeping
UPS does not provide expected
run time, low battery warning is
sounded prematurely.

Specifications

Type
Capacity
Input Voltage
Frequency
Output Voltage
Frequency
Battery Type
Capacity
Backup Time
(half load)
Typical
Recharge Time
LCD indicators Status
Audible Alarm Battery Mode
Power UPSilon2000
Maragement
Software
Protection Overload
Battery Low
Voltage
Short Circuit
Operating Temperature
Environment
Humidity
Audible Noise
Physical Size (mm)
Net Weight (Kg)
Performance
Uninterruptible Power
Possible Cause
POWER button was not been
pushed or been pushed too short.
PCB failure
Power cord loose
AC fuse burn out
Line voltage too high, too low or
black out
PCB failure
Overload
Battery is weak due to wear or
successive mains outages
CMP-UPS500 CMP-UPS650
500VA/300W 650VA/390W
165VAC-275VAC
50Hz
220V ± 10%
50Hz ± 0.5
Sealed, maintenance-free lead acid
1X12V 7Ah
Over 8 Minutes
8-hour
NORMAL, FAULT, BATTERY, CHARGE, OVERLOAD
Beeps every four seconds. Beeps every second if approaches final discharge
Option
Automatic cut off output and beep last for 30 Seconds
Automatic cut off output
Automatic cut off output and beep last for 30 Seconds
0 ~ 40°C
10%RH~90%RH
≤ 45dB(A)
330 × 85 × 155
6.5Kg
Action To Take
Press the POWER button and hold more
than 4 seconds.
Replace the PCB, call for service
Replace the power cord
Replace the AC fuse
normal condition
Replace the PCB, call for service
Remove the nonessential loads
Allow UPS to recharge battery for a
minimum of 8 hours. If up sounds low
battery warning prematurely, when retested,
battery should be replaced.
CMP-UPS800 CMP-UPS1000
800VA/480W 1000VA/600W
1X12V 9Ah
300 × 120 × 195
13.2Kg
CMP-UPS1200
1200VA/720W
2X12V 7Ah
