Presentation
LCD INDICATOR
1. OUTPUT VOLTAGE
2. BATTERY CAPACITY
3. NORMAL
4. OVERLOAD
5. BATTERY
6. POWER SWITCH
7. OUTPUT SOCKET
8. OUTPUT PHONE JACK
9. INPUT PHONE JACK
10. INPUT POWER CORD
11. FUSE SET
12. RS-232 INTERFACE PORT
STATUS
Shows the output voltage
Battery capacity indicator
Utility power in normal condition.
UPS overload. The buzzer emits continuous alarm for 30 seconds.
UPS transfer to backup or battery test mode.
The buzzer emits alarm every four seconds.
Power on-off/*Battery test and buzzer on-off.
Connect with load equipment.
Connect to the Tel/Fax/Modem by another phone line.
Insert the phone line into the jack.
Connect to the AC Power
Built-in fuse avoid damaged by short circuit or overload.
A connector to monitor the running status of the UPS (optional).
