Parts
1 5
22
1.
Front grille
2.
Safety screw
3.
Locking clip
4.
Guard ring
5.
Blade cap
6.
Fan blade
7.
Clamping nut
8.
Rear grille
9.
Motor shaft
10.
Motor shaft pins
11.
Front motor housing
03 | English
4
2 6
3
7 8
21
12.
Rear motor housing
13.
Angle of oscillation
14.
Angle of tilt
15.
Control panel
16.
Fan body securing screw
17.
Inner pole
18.
Height adjustment collar
19.
Outer pole
20.
Base plate
21.
Base screw and washer
22.
Remote control
10
11 12
14
13
9
15
16
17
18
19
20
